Product Description
The Level Twists Steel Tape Light Armored
Optical Fiber Cable ( GYTS )
| Introduction | ||||||
| The fibers are placed in a loose tube made of PBT. The tubes are filled with a water-resistant filling compound. A steel wire sometimes sheathed with PE for cable with high fiber count,locates in the center of core as a metallic strength member into a compact and circular cable core. An steel tape is applied around the cable core, which is filled with the filling compound to protect it from water ingress. Then, the cable is completed with a PE sheath. | ||||||
| Technical Parameters: | ||||||
| No. of fibers | No.of fibers per tube (max) | No.of elements | Tube diameter | Jacket | Short term tension | Short term crush |
| 4 count | 4 count | 1 count | 1.7±0.05mm | 9.3mm(1.8) | 1500N | 1000N/100mm |
| Test method and Mechanical Characteristic | ||||||
| Tensile Strength | confirm to IEC 794-1-E1 | Temperature requirement | Operation | -40℃ - +60℃ | ||
| Crush | confirm to IEC 794-1-E3 | Installation | -10℃ - +60℃ | |||
| Impact | confirm to IEC 794-1-E4 | Storage/Tran-sportation | -40℃ - +60℃ | |||
| Repeated bending | confirm to IEC 794-1-E6 | |||||
| Torsion | confirm to IEC 794-1-E7 | Temperature cycling test | confirm to IEC 794-1-F1 | |||
| Flexing | confirm to IEC 794-1-E8 | |||||
| Cable bend | confirm to IEC 794-1-E11 | Bending Radius | Unloaded | 10 times of outer diameter | ||
| Water penetration | confirm to IEC 794-1-F5B | Loaded | 20 times of outer diameter | |||
| Fiber Color Code | Color codes for loose tube & filler rod | |||||
| 1 | 2 | 3 | 4 | 1 | |||
| Blue | Orange | Green | Brown | Blue | |||
| Order Informations: | ||||||
| Marking | HELLOSIGNAL GYTS XXX (or Per customer's request) | |||||
| Inner Package | 1000m/Spool (or Per customer's request) | |||||
| Outer Package | Color Box, Pallet (or Per customer's request) | |||||
| Delivery time | Normally 25 days after received the deposit. | |||||
| Brand | HELLOSIGNAL® OR OEM | |||||
