HELLOSIGNAL CLASSIC 100/100 CY

  • HELLOSIGNAL CLASSIC 100/100 CY

  • hellosignal

  • 7142100

Availability:

Product Description

HELLOSIGNAL CLASSIC 100/100 CY

 HELLOSIGNAL CLASSIC 100 100 CYHELLOSIGNAL CLASSIC 100 100 CY。

Application

HELLOSIGNAL® CLASSIC 100 is a color-coded multi-conductor power and control cable for use in all electrical equipment in dry, damp, or wet conditions. It is a European-style cable, conforms to CE, and is available shielded or unshielded.

Recommended Applications

Control systems; assembly lines; control panels; data processing equipment; European machinery

Unshielded Construction

Conductors: Finely stranded bare copper

Insulation: PVC

Jacket: PVC; gray

Shielded Construction

Conductors: Finely stranded bare copper

Insulation: PVC

Shielding: Gray PVC inner jacket; tinned copper braid (85% coverage)

Jacket: PVC; transparent

Application Advantage

•  European color code for power
•  Conforms to CE standards
•  Available with inner jacket and tinned copper braid for EMI & RFI protection
•  Pressure-extruded jacket for improved flexibility

Technical data

 Minimum Bend Radius

for installation :  4 x cable diameter

shielded    :  6 x cable diameter

 Temperature Range

for flexible use    : 5°C to +70°C


for stationary use    : 40°C to +80°C


Technical data

 Nominal Voltage

unshielded:

≤ 16 AWG : 300/500V

≥ 14 AWG : 450/750V

shielded    :

≤ 18 AWG : 300/500V

≥ 16 AWG : 450/750V

Test Voltage

4000V

Conductor Stranding

Class 5 fine wire

     Color Code

VDE 0293-308: Chart 6, page 673

     Approvals

Based on VDE specifications

CE & RoHS










100 Product List

Item No.

Number of
Conductors

Nominal Outer(in)

Copper.weight (lbs/mft)

Approx.weight (lbs/mft)



20 AWG (0.50 mm²)

7142100

2

0.189

6

24



7142101

3

0.201

10

28


7142102

4

0.224

13

36


7142103

5

0.224

16

42



18 AWG (1.00 mm²)

7142105

2

0.244

13

36



7142106

3

0.236

19

44


7142107

4

0.256

26

53


7142108

5

0.280

32

63



16 AWG (1.50 mm²)

7142110

2

0.248

19

86



7142111

3

0.264

29

109


7142112

4

0.283

39

136


7142113

5

0.319

48

163


14 AWG (2.50 mm²)

7142115

2

0.350

32

86




7142116

3

0.378

48

109




7142117

4

0.421

65

136




7142118

5

0.465

81

163




12 AWG (4.00 mm²)

7142120

2

0.417

52

126




7142121

3

0.449

77

164




7142122

4

0.500

103

200




7142123

5

0.547

129

239




100 Product List

Item No.

Number of
Conductors

Nominal Outer(in)

Copper.weight (lbs/mft)

Approx.weight (lbs/mft)



10 AWG (6.00 mm²)

7142125

3

0.496

116

214




7142126

4

0.543

155

265




7142127

5

0.614

194

329




8 AWG (10 mm²)

7142130

3

0.626

194

342



7142131

4

0.693

258

437


7142132

5

0.776

323

532


6 AWG (16 mm²)

7142135

3

0.720

310

489



7142136

4

0.803

413

730


7142137

5

0.898

516

751




4 AWG (25 mm²)

7142140

3

0.906

677

1187



7142141

4

1.000

903

1416


7142142

5

1.122

1129

1771


2AWG (35 mm²)

7142145

3

1.008

677

1187




7142146

4

1.122

9.3

1416




7142147

5

1.256

1129

1771




1AWG (50 mm²)

7142150

3

1.220

968

1718




7142151

4

1.551

1290

1978




100 Product List

2 AWG (70 mm²)

7142155

3

1.390

1355

2139




7142156

4

1.551

1806

2750




3 AWG (95 mm²)

7142160

3

1.626

1839

3142




7142161

4

1.803

2451

3534




4 AWG (120 mm²)

7142165

3

1.874

2322

3776




7142166

4

2.091

3096

4694




350 KCMIL (185 mm²)

7142167

4

2.472

4774

5578




100 CY Product List

Item No.

Number of
Conductors

Nominal Outer(in)

Copper.weight (lbs/mft)

Approx.weight (lbs/mft)



20 AWG (0.50 mm²)

7142200

2

0.276

28

50




7142201

3

0.287

31

56




7142202

4

0.311

37

67




7142203

5

0.331

44

75




18 AWG (1.00 mm²)

7142205

2

0.311

38

66




7142206

3

0.323

44

75




7142207

4

0.343

52

87




7142208

5

0.374

60

103




16 AWG (1.50 mm²)

7142210

2

0.390

44

89




7142211

3

0.406

53

114




7142212

4

0.445

65

137




7142213

5

0.496

78

165




14 AWG (2.50 mm²)

7142215

3

0.465

98

142




7142216

4

0.531

112

208




7142217

5

0.575

134

319




12 AWG (4 mm²)

7142220

4

0.594

159

271




7142221

5

0.65

220

321




10 AWG (6 mm²)

7142225

4

0.654

214

350




7142226

5

0.717

296

419




8 AWG (10 mm²)

7142230

4

0.831

375

566




7142231

5

0.909

480

675




6 AWG (16 mm²)

7142235

4

0.941

540

782




7142236

5

1.055

706

1216




4 AWG (25 mm²)

7142240

4

1.157

866

1279




7142241

5

1.283

972

1595




2 AWG (35 mm²)

7142245

4

1.276

1138

1673




7142246

5

1.417

1327

1862




100 CY Product List

Item No.

Number of
Conductors

Nominal Outer(in)

Copper.weight (lbs/mft)

Approx.weight (lbs/mft)



1 AWG (50 mm²)

7142250

4

1.528

1574

2259




2 AWG (70 mm²)

7142260

4

1.72

2039

2499




3 AWG (95 mm²)

7142270

4

1.984

2725

3931




4 AWG (95 mm²)

7142280

4

2.236

3511

5046




300 KCMIL (150 mm²)

7142290

4

2.449

4233

5242




350 KCMIL (185 mm²)

7142291

4

2.669

5210

6630




Order Informations

Marking

HELLOSIGNAL CLASSIC 100/100 CY XXXFT/M

Package

100M/Reel, 300M/Wooden Spool

Delivery time

Normally 25 days after received the deposit.
