HELLOSIGNAL UL 1015 HOOK UP WIRE

  • UL 1015 HOOK UP WIRE

  • hellosignal

  • 7148100

Availability:

Product Description

UL 1015 HOOK UP WIRE

UL 1007 1569 HOOK UP WIRE

Application

UL 1015, UL Style 1015 may be used for the internal wiring of appliances.                                                            UL 1015, UL Style 1015 may be used for the internal wiring of appliances
where exposed to oil at a temperature not exceeding 60 oC or 80 oC.

Cable Construction

 Stranded Tinned Copper, Color Coded

Polyvinylchloride Insulation, .032 nominal










Technical data

Temperature range

 -40°C to +105°C

Voltage Rating

600 Volts










Product List

Item No.


AWG SIZE

Conductor  Stranded

NOM O.D.  (Inches)

NOM O.D.  (mm)

UL STYLE


7148100


26

Solid

0.08

2.03

1015



7148101


26

7/34

0.083

2.11

1015



7148102


24

Solid

0.084

2.13

1015



7148103


24

7/32

0.089

2.26

1015



7148104


22

Solid

0.09

2.29

1015



7148105


22

7/30

0.095

2.41

1015



7148106


20

Solid

0.095

2.41

1015



7148107


20

10/30

0.102

2.59

1015



7148108


18

Solid

0.106

2.69

1015



7148109


18

16/30

0.112

2.84

1015



7148110


16

Solid

0.115

2.92

1015



7148111


16

26/30

0.125

3.18

1015



7148112


14

Solid

0.128

3.25

1015



7148113


14

41/30

0.14

3.56

1015



7148114


12

Solid

0.145

3.68

1015



7148115


12

65/30

0.163

4.14

1015



7148116


10

65/28

0.18

4.57

1015



7148117


10

105/30

0.194

4.93

1015



Order Informations

Marking

HELLOSIGNAL UL 1007/1569 HOOK UP WIRE XXXFT/M

Package

100M/Reel, 300M/Wooden Spool

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL® OR OEM
