NO.7112121 SF/UTP CAT 5E BC PE

Construction

Conductor:

0.50±0.005mm Solid Bare Copper

Pairs:

4 Pairs

Insulation:

1.03±0.05 mm HDPE

Insulation Colors:

Blue-White/Blue,Orange-White/Orange

Green-White/Green,Brown-White/Brown

Shielded 1

PET Foil Overall

Shielded 2

Al/PET Foil,Foil face out Overall

Shileded 3

Braiding TC or AL_Mg

Rip Cord:

Cotton or Fibre

Out Jacket:

6.5±0.2 mm  UV-PE

Cross Section

COMPLIANCE （Reference Standard and Certificates)

· ISO/IEC 11801-1 Ed.1.0

· ANSI/TIA-568-C.2 、 ANSI/TIA-568.2-D

· UL444、UL1581、UL1666、IEC60332-1、EN50399

Application Support

· 1000BASE-T 、 100BASE-T 、 10BASE-T

· 1Volp、ISDN、 Token、 100MTPPDM、 Analogand Datavideo、 POE Type1,2,3,4

Electrical Characteristics

DC Resistance

＜9.38 Ohms/100m @20℃

DC Resistance unbalance

5% @ 20℃

Mutual Capacitance

5.6 nF/100m

Characteristic Impedance

    1 - 100 MHz : 100±15 Ohms

100 - 350 MHz : 100±22 Ohms

Max Frequency

100MHz

Capacitance Unbalance

330 pF/100m

NVP

67%

Delay Skew

≤ 45ns/100m

PHYSICAL PROPERTIES

Pulling Tension(Max)

≥13.5Mpa

Bend Radius(Min)

8×OD of Jacket

Operating Temperature

-20 to 80 ℃ （-4 to 176℉）

Performance Characteristics

Frequency

RL                     (Min.)

Insertion Loss(Max.)

Propagation Delay (Max.)

Delay Skew(Max.)

NEXT (Min.)

PSNEXT (Min.)

ELNEXT (Min.)

PSELNEXT (Min.)

MHz

dB

dB/100m

ns/100m

ns/100m

dB

dB

dB/100m

dB/100m

1

20.0

2.0

570.0

45.0

65.0

62.0

61.0

61.0

4

23.0

4.1

552.0

45.0

56.0

53.0

48.0

48.0

10

25.0

6.5

545.0

45.0

50.0

47.0

41.0

41.0

16

25.0

8.2

543.0

45.0

47.0

44.0

36.0

36.0

20

25.0

9.3

542.0

45.0

45.0

42.0

34.0

34.0

31.25

23.6

11.6

540.0

45.0

42.0

39.0

31.0

31.0

62.5

21.5

17.0

539.0

45.0

38.0

35.0

25.0

25.0

100

20.1

22.0

538.0

45.0

35.0

32.0

21.0

21.0

※Note: The above transmission performance tor the 100M, 20±2℃ under the conditions tested.

Order Informations

Marking

HELLOSIGNAL NO.7112121 SF/UTP CAT5E 4PR 24AWG BC UV-PE ...305M(1000FT)  (or Per customer's request)

Inner Package

305m/Spool,305m/Reel (or Per customer's request)

Outer Package

Color Box, Pallet (or Per customer's request)

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL® OR OEM
