SFC-250/75 Signal coaxial Cable

Construction Parameters:

Inner Conductor

0.93±0.02mm SC/SCCS-wire

Dielectric

5.27±0.05mm PTFE

Out Conductor

6.15±0.05mm Tinned Copper wier braid + Tin Soaked

Electrical Characteristics:

Capacitance

63.5pF/m

mpedance

75 Ω

Velocity of Propagation %

70

Max.Operating Frequency

18 GHz

Time Delay

4.7 ns/m

Max. Operating Voltage

3500 kVrms

Min.Screening Effectiveness
up to 18GHz

100 dB

Mechanical and Envrionmental Properties

Min.Bending Radius Static

25mm

Min.Bending Radius Repcated

120mm

Operating Temp Range

-55 to +125 ℃

Cross Section

Attenuation(20℃):

Frequency (GHZ)

Attenuation (dB/100m)

Power(wattsCW)

0.5

0.04

1653.00

1.0

0.24

1133.70

5.0

0.63

449.90

10.0

0.93

293.40

20.0

1.47

186.90

Tips for use:

Storage
Environment

Temperature: Do not over 30℃

Humidity: 20-65%

Order Informations:

Marking

HELLOSIGNAL SFC-250/75
Signal  COAXIAL CABLE 7101325×××M/FT

Package

Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL® OR OEM
