NO.7100163 RG59 BC 95% BC PVC CMP

Construction Parameters:

Inner Conductor

0.032"/0.81mm/20 AWG BC

Dielectric

0.135"/3.43mm  Foamed FEP

Shield 1

/

Shield 2

0.12mm Bare Copper
braid wire 95% coverage

Jacket

0.193"±0.006"/4.90±0.15mm PVC CMP

Jacket Thickness

0.032"/0.81mm

Application

For Use in Longer CCTV Run Lengths

Electrical Characteristics:

Inner Conductor Resistance

The Max. at 20℃ shall be <   33.4  Ω/km

10.2Ω/1000ft

Capacitance

52 ±3 pF/m       15.8 ±1 pF/ft

Impedance

75 ± 3 Ω

Return loss

between 5 and 1000MHz: > 22dB

Velocity of Propagation

0.85

Sparker Test (VAC)

4

Mechanical and Envrionmental Properties

Cable bend radius

10 times the cable diameter

Operating Temp Range

-20 ℃ to 60℃

Cable diamensions

0.193"±0.006"/4.90±0.15mm PVC CMP

Cross Section

Attenuation(20℃):

Frequency (MHZ)

Max Attenuation(dB/100ft)

Max Attenuation (dB/100m)

1

0.30

0.98

10

0.95

3.11

100

2.95

9.67

200

4.50

14.75

400

6.80

22.30

700

9.67

31.70

900

10.60

34.75

1000

11.47

37.61

Order Informations:

Marking

HELLOSIGNAL RG59 BC 95% BC PVC

CCTV COAXIAL CABLE 7100163 ×××M/FT

Package

Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL® OR OEM
