Declaration of performance (DoP)

The manufacturer is required to create a Declaration of Performance (DoP), a mandatory legal document that must be publicly available. In this document, the manufacturer must identify the product and its intended use, detailing the performance of the cable with respect to its essential characteristics. Presently, these characteristics include safety in case of fire (fire reaction as per EN 50575) and the emission of hazardous substances.

The DoP will contain the following information:
- Manufacturer’s name.
- Product code.
- Traceability.
- Use of this product.
- AVCP System.
- Notified Body.
- Declared performance and respective standards.
- Date and manufacturer’s stamp.

EuroClass CPR Class C Fire Resistant Cables/Fire Cables/Fire Alarm Cables

Cable Type	Description	Euroclass	DoP No.	Alternative name	Download
ZHFS-2C-4C X 0.22mm²-6.0mm²	Fire Resistant Cable 2 x 0,5 ÷ 6 mm²; 3 x 0,5 ÷ 6 mm²; 4 x 0,5 ÷ 6 mm²	Cca	ZC-C71109-C	PH120 Fire resistant Cable J-H(St)H FE180 Cable	Download

EuroClass D LAN Cables / Network Cables

Cable Type	Description	Euroclass	DoP No.	Alternative name	Download
U/UTP CAT6A LSZH	LAN Cable, CAT6A U/UTP LSZH PE Filler,23AWG Solid Bare Copper-class 1, Solid HDPE,Rip Cord, LSZH Sheath,6.3 OD	Dca	ZCU6-7112306-D	UTP CAT6A LSZH CAT6A UTP LSZH	Download
U/UTP CAT6 LSZH	LAN Cable, CAT6 U/UTP LSZH PE Filler,23AWG Solid Bare Copper-class 1, Solid HDPE,Rip Cord, LSZH Sheath,6.3 OD	Dca	ZCU6-7112206-D	UTP CAT6 LSZH CAT6 UTP LSZH	Download
U/UTP CAT5E LSZH	LAN Cable, CAT5e U/UTP LSZH 24AWG Solid Bare Copper,Solid HDPE, Rip Cord, LSZH Sheath,5.2 OD	Dca	ZCU5E-7112106-D	UTP CAT5E LSZH CAT5E UTP LSZH	Download
F/UTP CAT6A LSZH	LAN Cable, CAT6A F/UTP LSZH PE Filler,23AWG Solid Bare Copper-class 1, Solid HDPE,PET foil,Drain Wire, PET-Aluminum Foil Wrap, Rip Cord, LSZH Sheath,7.2 OD	Dca	ZCF6-7112316-D	FTP CAT6A LSZH CAT6A FTP LSZH	Download
F/UTP CAT6 LSZH	LAN Cable, CAT6 F/UTP LSZH PE Filler,23AWG Solid Bare Copper-class 1, Solid HDPE,PET foil,Drain Wire, PET-Aluminum Foil Wrap, Rip Cord, LSZH Sheath,7.2 OD	Dca	ZCF6-7112216-D	FTP CAT6 LSZH CAT6 FTP LSZH	Download
F/UTP CAT5E LSZH	LAN Cable, CAT5e F/UTP LSZH 24AWG Solid Bare Copper,Solid HDPE,PET Foil, Drain wire,PET-Aluminum Foil,Rip Cord LSZH Sheath,5.8 OD	Dca	ZCF5E-7112116-D	FTP CAT5E LSZH CAT5E FTP LSZH	Download

EuroClass E LAN Cables / Network Cables

Cable Type	Description	Euroclass	DoP No.	Alternative name	Download
U/UTP CAT6A LSZH	LAN Cable, CAT6A U/UTP LSZH PE Filler,23AWG Solid Bare Copper-class 1, Solid HDPE,Rip Cord, LSZH Sheath	Eca	ZCUU6A-7112306-E	U/UTP CAT6A LSZH CAT6A U/UTP LSZH	Download
U/UTP CAT6A PVC	LAN Cable, CAT6A U/UTP PVC PE Filler,23AWG Solid Bare Copper-class 1, Solid HDPE,Rip Cord, PVC Sheath	Eca	ZCUU6A-7112302-E	U/UTP CAT6A PVC CAT6A U/UTP PVC	Download
U/UTP CAT6 LSZH	LAN Cable, CAT6 U/UTP LSZH PE Filler,23AWG Solid Bare Copper-class 1, Solid HDPE,Rip Cord, LSZH Sheath	Eca	ZCU6-7112206-E	UTP CAT6 LSZH CAT6 UTP LSZH	Download
U/UTP CAT6 PVC	LAN Cable, CAT6 U/UTP PVC PE Filler,23AWG Solid Bare Copper-class 1, Solid HDPE,Rip Cord, PVC Sheath	Eca	ZCU6-7112202-E	UTP CAT6 PVC CAT6 UTP PVC	Download
U/UTP CAT5E LSZH	LAN Cable, CAT5e U/UTP LSZH 24AWG Solid Bare Copper,Solid HDPE, Rip Cord, LSZH Sheath	Eca	ZCU5E-7112106-E	UTP CAT5E LSZH CAT5E UTP LSZH	Download
U/UTP CAT5E PVC	LAN Cable, CAT5e U/UTP PVC 24AWG Solid Bare Copper,Solid HDPE, Rip Cord, PVC Sheath	Eca	ZCU5E-7112102-E	UTP CAT5E PVC CAT5E UTP PVC	Download
S/FTP CAT8 LSZH	LAN Cable, CAT8 S/FTP LSZH 0.60mm Solid Bare Copper-class 1, Foam PE,AL/PET Foil,Drain Wire, Braiding,Rip Cord, LSZH Sheath	Eca	ZCSF8-7112438-E	SFTP CAT8 LSZH CAT8 SFTP LSZH	Download
S/FTP CAT7A LSZH	LAN Cable, CAT7A S/FTP LSZH 0.58mm Solid Bare Copper-class 1, Foam PE,AL/PET Foil,Drain Wire, Braiding,Rip Cord, LSZH Sheath	Eca	ZCSF7A-7112426-E	SFTP CAT7A LSZH CAT7A SFTP LSZH	Download
S/FTP CAT7 LSZH	LAN Cable, CAT7 S/FTP LSZH 0.56mm Solid Bare Copper-class 1, Foam PE,AL/PET Foil,Drain Wire, Braiding,Rip Cord, LSZH Sheath	Eca	ZCSF7-7112406-E	S/FTP CAT7 LSZH CAT7 S/FTP LSZH	Download
SF/UTP CAT5E LSZH	LAN Cable, CAT5e SF/UTP LSZH 24AWG Solid Bare Copper,Solid HDPE,PET Foil, Drain wire,PET-Aluminum Foil,Braiding, Rip Cord,LSZH Sheath	Eca	ZCSF5E-7112126-E	SFTP CAT5E LSZH CAT5E SFTP LSZH	Download
SF/UTP CAT5E PVC	LAN Cable, CAT5e SF/UTP PVC 24AWG Solid Bare Copper,Solid HDPE,PET Foil, Drain wire,PET-Aluminum Foil,Braiding, Rip Cord,PVC Sheath	Eca	ZCSF5E-7112122-E	SFTP CAT5E PVC CAT5E SFTP PVC	Download
F/UTP CAT6A LSZH	LAN Cable, CAT6A F/UTP LSZH PE Filler,23AWG Solid Bare Copper-class 1, Solid HDPE,PET foil,Drain Wire, PET-Aluminum Foil Wrap, Rip Cord, LSZH Sheath	Eca	ZCFU6A-7112316-E	F/UTP CAT6A LSZH CAT6A F/UTP LSZH	Download
