What is the GYXTW fiber optic cable?

Views:10541     Author:James Xu      Publish Time: 18-09-2018      Origin:https://www.zion-communication.com/

GYXTW



        GYXTW(Central Tube Single Jacket Armored Cable)

Unitube Non-armored Cable

Structural features:Central tube cable(also called loose tube cables)

Optical fiber applications place:  Overhead laying

Fiber optic cable types:GYXTW

Fiber Numbers:1-12 fibers

Recommended index: 5 stars



Steel-polyethylene bonded sheathed cable for outdoor communication, metal reinforcing members, center tube, fully filled, parallel steel wire

Description


The fibers, 250μm, are positioned in a loose tube made of a high modulus plastic. The tube are filled with a water-resistant filling compound. The tube is wrapped with a layer of PSP longitudinally. Between the PSP and the loose tube water-blocking material is applied to keep the cable compact and watertight. Two parallel steel wires are placed at the two side of the steel tape. The parallel steel wires are placed at the two sides tape. The cable is completed with a polyethylene(PE) sheath.

Good mechanical and temperature performance.

High strength loose tube that is hydrolysis resistant.

Special tube filling compound ensure a critical protection of fiber.

Crush resistance and flexibility.

PSP enhancing moisture-proof.

Two parallel steel wires ensure tensile strength

Small diameter, light weight and friendly installation

Long delivery length

Fibre Colours




No.

1

2

3

4

5

6

Color

Blue

Orange

Green

Brown

Gray

White

No.

7

8

9

10

11

12

Color

Red

Black

Yellow

Violet

Pink

Aqua



Loose Tube Colours




No.

1

2

3

4

5

6

Color

Blue

Orange

Green

Brown

Gray

White

No.

7

8

9

10

11

12

Color

Red

Black

Yellow

Violet

Pink

Aqua







Fiber optic cable uses : The properties of single mode optical fiber (ITU-T Rec. G.652.D)





Item

Specification

Fiber type

Single mode

Fiber material

Doped silica

Attenuation coefficient

@ 1310 nm

@ 1383 nm

@ 1550 nm

@ 1625 nm



£ 0.35 dB/km

£ 0.32 dB/km

£ 0.21 dB/km

£ 0.24 dB/km

Point discontinuity

£ 0.05 dB

Cable cut-off wavelength

£ 1260 nm

Zero-dispersion wavelength

1300 ~ 1324 nm

Zero-dispersion slope

£ 0.092 ps/(nm2.km)

Chromatic dispersion

@ 1288 ~ 1339 nm

@ 1271 ~ 1360 nm

@ 1550 nm

@ 1625 nm

£3.5 ps/(nm. km)

£5.3 ps/(nm. km)

£18 ps/(nm. km)

£22 ps/(nm. km)

PMDQ (Quadrature average*)

£0.2 ps/km1/2

Mode field diameter @ 1310 nm

9.2±0.4 um

Core / Clad concentricity error

£ 0.5 um

Cladding diameter

125.0 ± 0.7 um

Cladding non-circularity

£1.0%

Primary coating diameter

245 ± 10 um

Proof test level

100 kpsi (=0.69 Gpa), 1%

Temperature dependence

0oC~ +70oC @ 1310 & 1550nm

£ 0.1 dB/km
