SAT 703 B Coax Cable 75 Ohm CATV coaxial Cable

  • SAT
  • hellosignal
  • 7100505
  • Coaxial Cable
  • 75 ohm
  • UL, ETL, CE, RoHS
  • 100m, 305m,500m,1000m,500ft,1000ft
  • roll, wooden spool, carton, pallet
  • 30KM
  • Normally 15 working days
  • NINGBO, SHANGHAI
  • T/T, L/C at sight, D/P at sight
Availability:

Specification

75 Ohm CATV coaxial Cable

CATV coaxial cable description
ZION COMMUNICATION supplies a wide range of CATV coaxial cables for today’s wireless
and broadband networks, through all areas of a network to transport broadband data.
These 75 Ohm screened low loss cables offer optimum performance for main trunk
/ distribution use in IRS, MATV and CATV systems where extended cable runs are required.
These products are available to support most systems, for CATV network distribution,
whatever part of the network, whether the trunk cables, head end cable products
or indeed the drop cables into the home.All HANGZHOU ZION COMMUNICATION CO.,LTD
CATV Coaxial cables comply with International standards within the industry. If you do not
find the product you need in then we offer the option of a special custom design cable.
Here you can choose between different constructions, jacket color or other materials etc.

Key Features
Physical Foamed dielectric, preventing water ingress, mechanically robust and stable
attenuation to 3 GHz Optimum shielding with excellent protection against interference
and improved mechanical strength Wide product range, to suit a wide range of applications
and environments, available in a range of jacket materials.

Why chose us as your partner?
  Price: You can get ultimate reasonable factory price of the CATV coaxial cable itself from us!
  Service: You will enjoy best service from our export team on price for import and export, shipping time, documents and custom policy, which will save cost ultimately  and create biggest value for you.
  Quality Guarantee:You will received 100% quality pass testing before sending to our customers; also we are responsible for all products during it’s normal lifetime.

900zion LOGO

SAT 703 B Coax Cable
75 Ohm CATV coaxial Cable
NO.7100505

Construction Parameters:

Inner Conductor

1.13mm±0.02mm Copper

Dielectric

4.8mm±0.10 Foamed PE

Shield 1

Aluminum PET

Shield 2

CuSn braid wire 45% coverage

Jacket

6.60±0.10mm PVC

Application

For Use in Longer CATV Run Lengths

Electrical Characteristics:

Inner Conductor                    Resistance

The Max. at 20 shall be <  17.5 Ω/km

Capacitance

54 ±3 pF/m

Impedance

75 ± 3 Ω

Return loss

between 5 and 1000MHz: > 22dB

Velocity of Propagation

0.85

Sparker Test (VAC)

4


Mechanical and Envrionmental Properties

Cable bend radius

10 times the cable diameter

Operating Temp Range

-20  to 60

Cable diamensions

6.6±0.15mm PVC


Cross Section


Attenuation(20℃):

Frequency (MHZ)

Max Attenuation(dB/100ft)

Max Attenuation (dB/100m)

5


1.60

10


2.10

30


3.20

50


4.10

200


7.90

300


9.80

470


12.40

862


17.10

1000


18.50

1750


24.90

2150


27.90

2400


29.60

3000


33.40


The Factory

900factory

We have a study and design label,a professional team of engineers and skilled workers, also with the advanced machines and modern factories which can provide our customers with outstanding quality, service, and pricing.
Monthly Production Capacity:
Wire (Copper/copper clad aluminium) drawing: 500 Metric Tons+
Coaxial Cable: 14,000KM+
Telephone Cable: 10,000KM+
Data & Computer Cable: 12,200KM+
Security & Fire Alarm Cable: 10,000KM+
Other Cable Types: 10,000KM+
Cable Accessories: 180,000pcs+
Telecom Accessories: 180,000pcs+

Packing

900packing

We have abundant types of packing for you,such as reel, plastic spool, wooden spool,pull box, colorful carton, pallet and many other more. Also our design team will supply you best solution of the packing for size ,firm and artistic outlooking.

Order Informations:

Marking

HELLOSIGNAL SAT 703 B Coax Cable
CATV COAXIAL CABLE 7100505 ×××M/FT

Package

Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL®OR OEM


Similar Type:

insert-link

Cond.Type
&Nom.D.C.R

Dielectric

Shielding

Shielding&
%Coverage

Jacket Type

Nom. Capacitance

Nom.Imp.Ω


SAT 50M
Coax Cable
NO.7100501

1.00mm
(SOL) Cu
21.9 Ω/km

Foamed
PE

Al/PET

CuSn
-Braid 38%

6.6mm
PVC

54 ±3 pF/m

75±3Ω


SAT 501
Coax Cable
NO.7100502

0.80mm
(SOL) Cu
34.3 Ω/km

Foamed
PE

Al/PET

CuSn
-Braid 47%

5.0mm
PVC

54 ±3 pF/m

75±3Ω


SAT 602
Coax Cable
NO.7100503

1.00mm
(SOL) Cu
21.9 Ω/km

Foamed
PE

Al/PET

CuSn
-Braid 40%

6.6mm
PVC

54 ±3 pF/m

75±3Ω


SAT 703 2G
Coax Cable
NO.7100504

1.13mm
(SOL) Cu
17.5 Ω/km

Foamed
PE

Al/PET

CuSn
-Braid 45%
3.6.3mm PE

7.60mm
PVC

54 ±3 pF/m

75±3Ω


SAT 703 ZH
Coax Cable
NO.7100506

1.13mm
(SOL) Cu
17.5 Ω/km

Foamed
PE

Al/PET

CuSn
-Braid 45%

6.6mm
LSZH

54 ±3 pF/m

75±3Ω
