SFC-086/25 Signal coaxial Cable

Construction Parameters:

Inner Conductor

0.93±0.02mm SC/SCCS-wire

Dielectric

1.65±0.05mm PTFE

Out Conductor

2.10±0.05mm Tinned Copper wier braid + Tin Soaked

Electrical Characteristics:

Capacitance

190.4 pF/m

Impedance

25 Ω

Velocity of Propagation %

70

Max.Operating Frequency

20  GHz

Time Delay

4.7 ns/m

Max. Operating Voltage

1500 kVrms

Min.Screening Effectiveness
up to 18GHz

100 dB

Mechanical and Envrionmental Properties

Min.Bending Radius Static

6mm

Min.Bending Radius Repcated

20mm

Operating Temp Range

-55 to +125 ℃

Cross Section

Attenuation(20℃):

Frequency (GHZ)

Attenuation (dB/100m)

Power(Watts CW)

0.5

0.59

195.00

1.0

0.84

128.00

5.0

1.96

55.60

10.0

2.86

36.50

20.0

4.23

25.30

Tips for use:

Storage
Environment

Temperature: Do not over 30℃

Humidity: 20-65%

Order Informations:

Marking

HELLOSIGNAL SFC-086/25
Signal  COAXIAL CABLE 7101303×××M/FT

Package

Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL® OR OEM
