NO.7100051 RG6 Q Dual PVC CMP

Construction Parameters:

Inner Conductor

0.040"/1.02mm/18AWG CCS

Dielectric

0.170"/4.32mm Foamed FEP

Shield 1

Bonded Aluminum Polyproylene

Shield 2

Aluminum braid wire 60% coverage

Shield 3

Laminated Aluminum Tape(Non-Bonded)

Shield 4

Aluminum braid wire 40% coverage

Jacket

0.260"±0.006"/6.6±0.15mm PVC CMP

Jacket Thickness

0.015"/0.38mm

Application

For Use in Longer CATV Run Lengths

Electrical Characteristics:

Inner Conductor Resistance

The Max. at 20℃ shall be <  87 Ω/km

26.6Ω/1000ft

Capacitance

52 ±3 pF/m          1 15.9 ±0.9 pF/ft

Impedance

75 ± 3 Ω

Return loss

between 5 and 1000MHz: > 22dB

Velocity of Propagation

0.85

Sparker Test (VAC)

4

Mechanical and Envrionmental Properties

Cable bend radius

10 times the cable diameter

Operating Temp Range

-20 ℃ to 60℃

Cable diamensions

2×（0.260"±0.006"/6.6±0.15mm PVC CMP）

Cross Section

Attenuation(20℃):

Frequency (MHZ)

Max Attenuation(dB/100ft)

Max Attenuation (dB/100m)

1

0.50

1.64

10

0.92

3.02

50

1.60

5.25

100

2.40

7.87

200

3.40

11.14

400

4.80

15.74

700

6.50

21.31

900

7.70

25.24

1000

8.10

26.55

1200

9.00

29.50

1450

9.90

32.46

1800

11.20

36.72

2200

13.00

42.62

3000

15.30

50.16

Order Informations:

Marking

HELLOSIGNAL RG6 Q Dual PVC CMP
CATV COAXIAL CABLE 7100051 ×××M/FT

Package

Inquired Length on Reel,Plastic Spool,wooden Spool,pallet …

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL® OR OEM
