RG7 S 90% PE M 75 Ohm CATV coaxial Cable

  • RG7

  • hellosignal

  • 7100808

  • Coaxial Cable

  • 75 ohm

  • UL, ETL, CE, RoHS

  • 100m, 305m,500m,1000m,500ft,1000ft

  • roll, wooden spool, carton, pallet

  • 30KM

  • Normally 15 working days

  • NINGBO, SHANGHAI

  • T/T, L/C at sight, D/P at sight

Availability:

Specification

zion LOGORG7 S 90% PE M

75 Ohm CATV coaxial Cable

NO.7100808

Construction Parameters:

Inner Conductor

0.051"/1.29mm/16AWG Bare copper

Dielectric

0.225"/5.72mm Foamed PE

Shield 1

0.246"/6.25mm Bonded Aluminum PET

Shield 2

Aluminum braid wire 90% coverage

Jacket

0.319"±0.008"/8.10±0.20mm PE

Jacket Thickness

0.031"/0.78mm

Messenger

1.83mm Steel

Minium Breaking Strength

166kg

Application

For Use in Longer CATV Run Lengths

Electrical Characteristics:

Inner Conductor Resistance


The Max.at 20 shall be<91.2 Ω/km

(27.8Ω/1000ft)

Capacitance

50 ±3 pF/m


Impedance

75 ± 3 Ω

Structural Return Loss

20 dB

Velocity of Propagation

0.82

Sparker Test (VAC)

4


Mechanical and Envrionmental Properties

Cable bend radius

10 times the cable diameter

Operating Temp Range

-40  to 80

Cable diamensions

0.319"±0.008"/8.10±0.20mm PE


Cross Section


Attenuation(20℃):

Frequency (MHZ)

Max Attenuation(dB/100ft)

Max Attenuation (dB/100m)

5

0.47

1.54

55

1.25

4.10

211

2.36

7.74

250

2.56

8.40

270

2.68

8.78

300

2.82

9.25

330

2.96

9.72

350

3.05

10.01

400

3.27

10.73

450

3.46

11.35

500

3.67

12.04

550

3.85

12.63

600

4.05

13.28

750

4.57

14.99

870

4.96

16.28

1000

5.32

17.45

Order Informations:

Marking

HELLOSIGNAL RG7 S 90% PE M

CATV COAXIAL CABLE 7100808 ×××M/FT

Package

Inquired Length on Reel,wooden Spool,pallet …

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL® OR OEM
