EN50200 Fire alarm cable
hellosignal
7110458
Fire Alarm Cable
UL, ETL, CE, CPR, RoHS, LPCB
100m,500m,500ft,1000ft
roll, wooden spool, carton, pallet
10KM
Normally 15 working days
NINGBO, SHANGHAI
T/T, L/C at sight, D/P at sight
PH120 3×2.5mm²
Fire Alarm Cables
NO.7110458
Conductor:
2.5 mm² plain annealed copper wire.
Compliant with EN 60228 (available in Class 1, 2, or 5).
Insulation:
Made of fire‐resistant silicone rubber.
Meets standards BS 6387 CWZ, EN 50200 PH120, and IEC 60331.
A “dielectric” layer was applied with three layers at 0.0126″ (approximately 3.2 mm) each.
The insulation color is Brown/Black/Grey.
Flame Barrier:
Constructed using fiberglass tape to provide additional fire protection.
Drain Wire:
0.80 mm solid tinned copper to ensure proper earthing and shield termination.
Shielding:
Aluminum polyester (PET) tape provides 100% coverage with 20% overlapping for effective EMI protection.
Jacket (Outer Sheath):
FR-LSZH (fire retardant, low smoke, zero halogen) material.
Available in Red or White.
Diameter over jacket: 0.348″ ± 0.006″ (approximately 8.85 ± 0.15 mm).
Jacket construction meets additional flame performance standards (HFFR EN 50290-2, BS7655 LTS1/LTS3, VDE 0207).
Print Legend:
The cable is marked as “HELLOSIGNAL Fire Alarm Cable PH120 2.5mm² 3 Cores Class N” along with reference details such as “BC BS 50200:2006 NO.7110458 ××××M/FT.”
Minimum Bend Radius: 8× the overall cable diameter.
Insulation Resistance: Minimum of 200 MΩ/km.
Temperature Range: Operating between –30℃ and +90℃.
Test Voltage: Rated for 2000 V testing.
Operating Voltage: Maximum operating voltage specified as 300 V/600 V.
Conductor Resistance:
For Class 1 and 2: Maximum of 7.4 Ω/km.
For Class 5: Maximum of 8.0 Ω/km.
Note: Current carrying capacity and nominal capacitance were not explicitly specified.
The cable is rigorously tested and complies with multiple international standards covering:
Flame tests (e.g., BS 4066 parts 1 & 3, IEC 60332 series)
Insulation integrity and smoke density (e.g., IEC/EN 61034, IEC 60754-2)
Corrosive gas measurement and additional tests (BS 6387 CWZ, EN 50200 PH120, etc.)
Packaging Options: Available on 100 m, 200 m, and 500 m wooden spools.
Delivery Time: Typically 25 days after receipt of the deposit.
Branding: Supplied as HELLOSIGNAL® or under OEM branding.
