NO.7110457 PH120 3×1.5mm² Fire Alarm Cables

PH120 3×1.5mm²

Fire Alarm Cables

NO.7110457

■ Cable Construction

Conductor: 1.5 mm² Plain annealed copper wire, class 1, 2, or 5 according to EN60228.

Insulation:Material: Fire-resistant silicone rubber (BS 6387 CWZ, EN 50200 PH120, IEC 60331)

Diameter over Dielectric: 3 × (0.0102" (2.6 mm))

Insulation Color: Brown (Brn) / Black (Blk) / Gray (Gry)

Flame Barrier: Fibre Glass Tape

Drain Wire: 0.80 mm Solid tinned copper

Shield: Aluminum PET (100% coverage, 20% overlapping)

Jacket: FR-LSZH (Red or White)

Diameter over Jacket: 0.299" ± 0.006" (7.60 ± 0.15 mm)

Standards: HFFR EN 50290-2, BS 7655 LTS1/LTS3, VDE 0207

Print Legend: HELLOSIGNAL Fire Alarm Cable PH120 1.5mm² 3 Cores Class N

BC BS 50200:2006 NO.7110457 ××××M/FT

■ Electrical Properties (at20℃):

Minimum Bend Radius: 8 × Diameter

Minimum Insulation Resistance: 200 MΩ/km

Maximum Working Temperature: -30°C to +90°C

Test Voltage: 2000 V

Maximum Operating Voltage: 300 V / 600 V

Maximum Resistance of Conductor:

Class 1, 2: 12 Ω/km

Class 5: 12.9 Ω/km

■ Cross Section:

■ Test Standards

Flame Tests:

• BS 4066 Part 1 & 3

• IEC 60331

• BS 6387 CWZ

• IEC 60332-3-24

• EN 50200 PH120

• HD 606

• BS 6425

• IEC/EN 60332-1

Insulation Integrity:

• BS 7622

Smoke Density:

• IEC/EN 61034

Corrosive Gas Measurement:

• BS EN 50267-2-2

• EN 50266-2-4

• IEC 60754-2

■ Order Information:

Package: 100M/Wooden Spool,200M/Wooden Spool,500M/Wooden Spool

Delivery Time: Normally 25 days after receiving the deposit.

Brand: HELLOSIGNAL®OEM (Original Equipment Manufacturer)
