HELLOSIGNAL Hybrid electronic control cable for servo motor

  • Hybrid electronic control cable for servo motor
  • hellosignal
  • 7147090
Quantity:

Hybrid electronic control cable for

servo motor

Application

This cable apply to wiring for intelligent system of industrial robots. And it apply to intelligent
control system of integrated electric cabinet and the system of control cabine.It has
good performance of resistant to interference.

Cable Construction

Conductor: flexible ultra-fine stranded copper wirer

Insulation: Special-thermoplastic TPE mixture

Insulation color:one is yellow/green insulated wire,

                    others are white insulated wire print black font

Filler: special material of filler

Shield: high strength tinned copper braid

Jacket: high abrasion and heat resistant PVC jacket;black

Product Feature

Fire resistance meets FT1&IEC60332-1

Good mechanical properties;Good oil resistant

Good capability of electric insulation and resistant to chemicals

Cross Section

 Hybrid electronic control cable for servo motor

Technical data

Temperature range

Bend:   -30 to 80

Static:  -50 to 80

Rated voltage

UL600V

IEC/VDE 450V/750V

Insulation resistance

20≥100M ohm/km

Min bending radius

Fixed 5D(D=cable diameter)

Test voltage

core/core 4000V/min

core/shied3500V/min

Product List

Item No.

Spec.(core*Nominal cross-section)mm²

Nominal
OD(mm)

Copper.weight approx (kg/km)

Weight approx(kg/km)

7147090

Interbus(2*0.25mm²)+Devicenet(2*0.34mm²)             +(2*1.0mm²)+1.0mm²

210.5

65

135

7147091

Interbus(2P*0.25mm²)+Devicenet(2P*0.34mm²)           +(2P*1.0mm²)+profibus(2*0.34mm²)+1.0mm²

214.5

130

270

Order Informations

Marking

HELLOSIGNAL Hybrid electronic control cable for servo motor XXXFT/M

Package

100M/Reel, 300M/Wooden Spool

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL® OR OEM
