HELLOSIGNAL Z-ROB-SB PUR screened control cable for robot(Twisted pair)

  • Z-ROB-SB PUR screened control cable for robot(Twisted pair)
  • hellosignal
  • 7147050

Z-ROB-SB PUR screened control cable
for robot(Twisted pair)

Application

This cable is used in the occasion with torsion movement.It is used as connecting cables
in small industrial robot and mechanical arm.It also can be used as drag chain cables
for high speed operation.It apply to indoor or outdoor cold environment.Halogen free.

Cable Construction

Conductor:high bending strength ultra-fine stranded copper conductor

Insulation: TPEE mixture insulation

Shield:high strength tinned copper braid

Jacket:high abrasion resistant PVC jacket

Product Feature

This product meets the requirements of UL758 style 20375

Fire resistance meets VW-1&FT1&IEC60332-1

High tensile strength,abrasion,impact and torsion resistant

High property of bending strength and flexibility

Good performance of resistant to signal interference

extremely oil resistant

Cross Section

Z-ROB-SB PUR screened control cable .

Technical data

Temperature range

Bend:   -40 to 105

Static:  -50 to 105

Rated voltage

UL/CSA    300V

IEC/VDE   ≤0.5mm²;300/300V

                  ≥0.5mm²;300/500V

Insulation resistance

20≥1000M ohm/km

Min bending radius

Fixed 3.0D(D=cable diameter)

Moving: 5.0D(D=cable diameter)

Torsion angle:

Moving:±180°/m

          Application of drag chain≥20 million times

Product List

Item No.

Spec.(core*Nominal cross-section)mm²

Nominal
OD(mm)

Copper.weight approx (kg/km)

Weight approx(kg/km)

7147050

2P*0.14

6.6

18.5

47.9

7147051

4P*0.14

7.2

25.7

61.9

7147052

6P*0.14

8.4

34.9

77.7

7147053

10P*0.14

10.4

55.4

111.8

7147054

2P*0.20

7.2

23.5

56.6

7147055

4P*0.20

7.8

33.7

75

7147056

6P*0.20

9.1

46.2

94.3

7147057

10P*0.20

11.4

74.2

137.2

7147058

15P*0.20

14.8

111.9

217.7

7147059

2P*0.30

7.7

28.9

64.8

7147060

4P*0.30

8.5

43.5

88.8

7147061

6P*0.30

10

63.7

117.1

7147062

10P*0.30

12.9

97.1

178

7147063

15P*0.30

16.2

146.1

263.5

7147064

2P*0.50

8.5

39.5

80.4

7147065

4P*0.50

9.4

62.4

114.8

7147066

6P*0.50

11.2

92.2

154

7147067

10P*0.50

14.5

148.8

243.3

7147068

15P*0.50

18.3

215.1

355.6

7147069

2P*0.75

10.2

57.8

110

7147070

4P*0.75

11.2

90.9

159.1

7147071

6P*0.75

13.8

133.8

226

7147072

10P*0.75

17.4

207.9

329.8

Order Informations

Marking

HELLOSIGNAL Z-ROB-SB PUR screened control cable
for robot(Twisted pair) XXXFT/M

Package

100M/Reel, 300M/Wooden Spool

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL® OR OEM
