Simplex Armored Fiber Patch Cable
HELLOSIGNAL
Fiber System Equipment
Normally 25 working days
NINGBO, SHANGHAI
T/T, L/C at sight, D/P at sight
A simplex armored fiber patch cable is an exclusive one-fiber optic cable, strongly built, and designed
for harsh demanding localities. The term simplex is used to describe its one-strand structure,
and most often this type of data transfer is used in one-way communication.
Reinforced by a soft metal protective tube or armored braided wire sheath,
these wires guarantee far-above average damage resistance from forces like
crushing, bending, or cuts. They have also become necessary tools for the installer in situating efficient
and safe transportation in such locations as the base.
Notwithstanding their construction as complex armored fiber patch cables, these cables are still very flexible,
if not like standard fiber optic cables, allowing for tight bending that does not break the cables. Consequently,
they are able to withstand or keep on performing in situations with excessive amounts of dust, oil, gas, humidity,
heat, or even in areas with the possibility of damage from mice and insects. This is, therefore,
the main reason they are extensively used in heavy-duty industries, data units,
and wherever protection of excess fiber is a priority.
Armored fiber optic patch cables are made with special features to guarantee their solidity
and protection in demanding locations. Here are the critical aspects:
Protective Armored Layer:
Sometimes consisting of either stainless steel or aluminum,
and on some occasions even of a durable synthetic substance, the armor layer is there to
keep the inner fiber safe from physical harm, like crushing, bending, or impact.
High Flexibility:
However, these cables with the armor do not lose their flexibility, which means
they can be easily handled and wired in different configurations, like in a difficult space or
a tight area. This design makes it possible for painless laying of tracks without fiber damage.
Rodent-Resistant:
The associated armor not only fends off the problem but also the cause of the damage.
The products' suitability in places where vermin cause problems results.
High Tensile Strength:
The reinforcement aspect of the design results in high tensile syndrome,
which will allow the cable to be pulled or stressed during installation and maintenance.
Fire-Retardant Coating:
A large number of armored fiber cables are manufactured using flameproof material,
which guarantees more safety under a condition of fire being highly risky.
Moisture and Chemical Resistance:
The fibers of the armored cables are often coated to prevent moisture
and some chemicals, which provide protection of the fiber core
from the negative influence of wet, outdoor, or industrial environments.
Easy Installation:
Unlike conduit-protected fibers, armored fiber patch cables do not need
the addition of an outer cover that requires installation work and part costs decrease significantly.
Enhanced Security:
With a stronger exterior, these cables become a tough nut to crack,
which is the property that makes them perfect for secure places.
Compatibility:
Offered in both single-mode and multimode fiber types and the connectors
such as LC, SC, and ST are also compatible, so the cables are widely used
nd can be operated in different working environments.
Connector Type:
LC Connector (Lucent Connector): Available in Standard, Uniboot, and High-Density configurations,
and compatible with SFP, SFP+, and XFP transceivers. This small-form-factor connector
features a latch mechanism, making it perfect for high-density applications.
Its compact design is ideal for space-saving setups in data centers and telecom networks.
SC Connector (Subscriber Connector or Standard Connector): Offered with Standard and Short boots,
and commonly used in Telecom, GPON, EPON, and GBIC applications. Known for its push-pull design,
the SC connector is widely used for its ease of use and reliable performance,
making it popular in cable TV networks and data communication systems.
FC Connector (Ferrule Connector): Available in Standard boot, suitable for Datacom, Telecom,
measurement equipment, and single-mode laser applications. With its threaded design,
the FC connector ensures a secure connection, making it suitable
for high-vibration environments and long-distance industrial applications.
ST Connector (Straight Tip): Equipped with a Standard boot, the ST connector has a bayonet-style lock.
Commonly used in multimode networks like campus and building installations,
it offers a quick release and lock system, providing convenience in patch panels and distribution frames.
Fiber Type
OM1(62.5/125),
OM2(50(125),
OM3, OM4 (50/125,Laser Optimization)]
Core Size
Most commonly in 50/125 μm or 62.5/125 μm.
Polishing
Usually the type of polish is Optical Fiber Ribbon Cable (UPC) for a low signal loss,
though angle type polish (APC) may be available as an option for specific applications.
Cable Jacket Options
Offered in PVC (Polyvinyl Chloride), LSZH (Low Smoke Zero Halogen),
and Plenum-rated types for compliance with the different installation environment safety regulations.
| Minimum allowable Tensile Strength (N) | minimum allowable Crush Load (N/100mm) | Minimum Bending Radius (MM) | |||
| short term | long term | short term | long term | short term | long term |
| 1000 | 300 | 1000 | 500 | 20D | 10D |
| 1000 | 300 | 1000 | 500 | 20D | 10D |
| 1000 | 300 | 1000 | 500 | 20D | 10D |
Mechanical Specification
Ceramic: ≤0.3dB(IEC Grade C), ≤0.12dB(IEC Grade B)
Return loss: SM UPC ≥ 50dB(min), SM APC ≥ 60dB(min), MM PC ≥ 35dB(min)
Tensile Strength(N): Long term 100; short term:200
Crush Resistance(N/100mm): Long term 3000; short term:5000
Interchangeability &Vibration: ≤0.2dB
Operation&Storage temperature: -45~85°C
Fiber optic patch cords are built to conform with the standards and regulations set by international bodies so that they exhibit compatibility, good performance, and safety. These requirements assist in ensuring uniformity and the following of specific procedures in manufacturing, installation, and operation. In this regard, some of the critical standards and certifications are explained below.
ISO/IEC standards: ISO and IEC are the refinements for fiber optic parts, including patch cords. The standards like ISO/IEC 11801 for cabling system structures and ISO/IEC 24702 for patch cords necessitate optimal functioning, testing, and sound installation principles.
Telecommunications Industry Association (TIA): For instance, TIA-568 series standards, which were established by TIA, give directions for telecommunications cabling in commercial buildings, which includes the patch cords for fiber optic systems. These standards are important as they ensure system compatibility, besides ensuring system performance.
National Electrical Code (NEC): Fiber optic cables and patch cords in different nations adhere to the NEC standards for overall safety and installation to avoid fire incidents, which are followed by standards and building codes.RoHS Compliance: RoHS (Restriction of Hazardous Substances) is the directive which sets the perimeter, specifically limiting the use of toxic substances, such as lead and mercury, in EEEs (Electronic and Electrical Equipment), e.g., fiber optic patch cords. RoHS compliance is an assurance that both the production and the disposal of the said components are safe for the environment.
UL Certification: Underwriters Laboratories (UL) certification is a must-have to guarantee that you have chosen safe and satisfying fiber optic patch cords to work within North American standards. UL-listed components pass comprehensive testing and careful evaluation to ensure compliance with the demands of the sector and to exhibit reliability.
CE Marking: CE marking is a symbol of adherence to EU directives fulfilling health, safety (products), and environmental protection specifications. These fiber optic patch cords carrying the CE mark incorporate mandatory EU quality and performance requirements.
FCC Compliance: In the United States of America (USA), the Federal Communications Commission (FCC) responds to emission of EMI (electromagnetic interference) from electronic devices, including fiber optic patch cords, under their rules. The FCC compliance mandates the compatibility of the same with other electronic devices so that minimal interference with them may be there.
Meeting these requirements and standards helps in the product development process of fiber optic patch cords, thus producing high-quality products that are reliable in different scenarios and meet applicable sector safety and environmental protection regulations. During a search for patch cords, firms and organizations should pick those with the proof of the certifications which indicate that they are in compliance with the relevant industry standards and are properly installed, thus ensuring compatibility, reliability, and adherence to the best practices.
Procuring fiber optic patch cords is not only about the cost, but also about choosing the right supplier to ensure the best quality, reliability, and cost-effectiveness. To make the right choice, consider the following:
Quality vs. Cost: Bear in mind that the cost is not the only criterion in such cases, hence, quality should be prioritized to avoid issues like signal loss, performance degradation, and frequent replacements. High-quality patch cords are generally manufactured from quality material, designed using the latest production technologies, and aligned with stringent standard norms, thus boasting better performance and service life.
Supplier Reputation: Work with credible suppliers that have been delivering dependable goods and services for a long time, and have gained customer appreciation and credibility. Certified suppliers (for example, ISO, UL) as well as positive feedback from other customers are two main indicators of the concern about quality and customer satisfaction.
Product Warranty: See the terms of the warranty, according to which the supplier guarantees protection against manufacturing defects and instances of remuneration of failed equipment. The prolonged warranty term stands for a high-quality issue-free product creation, at the same time the anxiety to satisfy the client is low.
Customization Options: Various applications might need the use of custom-built patch cords having specified lengths, connectors, or operation features. Opt for dealers who have the ability to provide customization of products in order to fulfill clients’ needs effectively.
Compatibility and Interoperability: Take caution during your purchase of patch cords to see if they fit with the protocols and systems you have. While preferring connectors and fiber types (whether single-mode or multi-mode) for the network infrastructure, check they match your system’s transmission requirements.
Bulk Purchasing and Discounts: For huge projects or those demanding many patch cords, you can try to know from the potential suppliers about bulk gets that may attract discounts. Such an action can also translate into huge savings since procurement outlays will be reduced without compromising the conditions of the obtained products.
Technical Support and Services: Judge the technical support of the company; this may contain the selection of the right product line or the provision of guidelines or troubleshooting to aid in the installation process. Access to comfortable technical support allows for a proper installation of a patch cord and immediate troubleshooting.
Supply Chain Stability: Weatherproof yourself the supply chain of the supplier, being aware that it is strong with proper inventory management controls if the situation with patch cords supply is to remain good. This results in lowering the procurement length and the risk of delays decreases as well.
By careful scrutiny of these benchmarks, a company or organization can go for the optimal choice of fibre optic patch cords blend of the price factor and the need for highly qualified technical background and assistance. Quality factor with regard to the supply chain is critical in bringing about an efficient and reliable network, which is pivotal in data and other information transmissions.
