3C-2V
hellosignal
KT0737
Specification
3C-2V CCTV COAXIAL CABLE
BC Conductor BC Braiding
| Construction Parameters: | ||
| Inner Conductor | 0.50±0.01mm Bare Copper | |
| Dielectric | 3.2±0.05mm Foam PE | |
| First Shield | Nom. 4.15mm | |
| Strands | 0.005"/0.12mm Bare Copper | |
| % Coverage | 95 nom | |
| Jacket | 5.00±0.1mm PVC | |
| Application | For Use in Intermediate CCTV Run Lengths | |
| Limited Length | ||
| Electrical Characteristics: | ||
| Capacitance | 72±3 pF/m | |
| Impedance | 75±3 Ω | |
| Resistance at 20℃ | 91.4 Ohms/KM | |
| Return loss | between 5 and 1000MHz: > 20dB | |
| Velocity of Propagation | 0.66 | |
| Shielding Effectiveness(>dB) | 70 | |
| Max Operating Voltage(KVMS) | 3 | |
| Operating Temp Range (PVC) | -20 ℃ to 65℃ | |
| RoHS | YES | |
| Attenuation(20℃): | ||
| Frequency (MHZ) | Max Attenuation (dB/100ft) | Max Attenuation (dB/100m) |
| 5 | ||
| 55 | 9.65 | |
| 100 | 13.75 | |
| 300 | 24.27 | |
| 500 | 31.74 | |
| 1000 | 45.95 | |
| Order Informations: | ||
| Marking | HELLOSIGNAL KT0737 3C-2V BC 95% BC COAXIAL CABLEXXXFT/M | |
| Inner Package | 100M/REEL, 500M/Wooden Spool,Pallet | |
| Delivery time | Normally 20-25 days after received the deposit. | |
| More informations | please contact with us. | |
| Brand | HELLOSIGNAL® OR OEM | |
