NO.7100902 2.5C-2V

Construction Parameters:

Inner Conductor

0.40mm BC

Dielectric

2.4mm SPE

Shield

0.12mm×6×16 BC Braid(L=20)

Jacket

4.0±0.5mmPVC

Jacket Thickness

0.05mm

Application

For Use in Longer CCTV Run Lengths

Electrical Characteristics:

Inner Conductor Resistance

The Max. at 20℃ shall be<145Ω/km

Capacitance

69±4 pF/m

Impedance

75 ± 3 Ω

Return loss

between 5 and 1000MHz: > 20dB

Velocity of Propagation

Sparker Test (VAC)

1

Mechanical and Envrionmental Properties

Cable bend radius

10 times the cable diameter

Operating Temp Range

-20 ℃ to 65℃

Cable diamensions

Cross Section

Attenuation(20℃):

Frequency (MHZ)

Max Attenuation(dB/100ft)

Max Attenuation (dB/100m)

10

4.2

30

9.3

72

88

90

135

180

220

19

270

440

750

770

Order Informations:

Marking

HELLOSIGNAL 2.5C-2V

CCTV COAXIAL CABLE 7100902 ×××M/FT

Package

Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL^® OR OEM
