NO.7100903 3C-2V

3C-2V

75 Ohm CCTV coaxial Cable

NO.7100903

■ Construction Parameters:

Inner Conductor: 0.50mm BC

Dielectric: 3.1mm SPE

Shield: 6×16×0.12mm BC

Jacket: 5.4±0.5mmPVC

Jacket Thickness: 0.08mm

Application: For Use in Longer CCTV Run Lengths

■ Electrical Characteristics:

Inner Conductor Resistance: The Max. at 20℃ shall be<145Ω/km

Capacitance: 69±4 pF/m

Impedance: 75 ± 3 Ω

Return loss: between 5 and 1000MHz:  > 20dB

Velocity of Propagation:

Sparker Test (VAC): 1

■ Mechanical and Environmental Properties:

Cable bend radius: 10 times the cable diameter

Operating Temp Range: -20 ℃ to 65℃

■ Cross Section:

■ Attenuation(20℃):

■ Order Information:

Marking: HELLOSIGNAL 3C-2V   CCTV COAXIAL CABLE 7100903 ×××M/FT

Package: Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …

Delivery time: Normally 25 days after received the deposit.

Brand: HELLOSIGNAL® OR OEM
