10C-2V
hellosignal
7100910
Coaxial Cable
75 ohm
UL, ETL, CE, RoHS
100m, 305m,500m,1000m,500ft,1000ft
roll, wooden spool, carton, pallet
30KM
Normally 15 working days
NINGBO, SHANGHAI
T/T, L/C at sight, D/P at sight
75 Ohm CCTV coaxial Cable NO.7100910 | |||
Construction Parameters: | |||
Inner Conductor | 7×0.50mmBC | ||
Dielectric | 9.4mmSPE | ||
Shield | 0.20mm×10×24 BC Braid(L=60) | ||
Jacket | 13±0.5mmPVC | ||
Jacket Thickness | 1.3mm | ||
Application | For Use in Longer CCTV Run Lengths | ||
Electrical Characteristics: | |||
Inner Conductor Resistance | The Max. at 20℃ shall be<13.1Ω/km | ||
Capacitance | 67±3 pF/m | ||
Impedance | 75 ± 3 Ω | ||
Return loss | between 5 and 1000MHz: > 20dB | ||
Velocity of Propagation | |||
Sparker Test (VAC) | 1 | ||
Mechanical and Envrionmental Properties | |||
Cable bend radius | 10 times the cable diameter | ||
Operating Temp Range | -20 ℃ to 65℃ | ||
Cable diamensions | |||
Cross Section | |||
| |||
Attenuation(20℃): | |||
Frequency (MHZ) | Max Attenuation(dB/100ft) | Max Attenuation (dB/100m) | |
10 | |||
30 | |||
72 | |||
88 | |||
90 | |||
135 | |||
180 | |||
220 | |||
270 | |||
440 | |||
750 | |||
770 | |||
1300 | |||
2400 | |||
Order Informations: | |||
Marking | HELLOSIGNAL 10C-2V CCTV COAXIAL CABLE 7100910 ×××M/FT | ||
Package | Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet … | ||
Delivery time | Normally 25 days after received the deposit. | ||
Brand | HELLOSIGNAL® OR OEM | ||
75 Ohm CCTV coaxial Cable NO.7100910 | |||
Construction Parameters: | |||
Inner Conductor | 7×0.50mmBC | ||
Dielectric | 9.4mmSPE | ||
Shield | 0.20mm×10×24 BC Braid(L=60) | ||
Jacket | 13±0.5mmPVC | ||
Jacket Thickness | 1.3mm | ||
Application | For Use in Longer CCTV Run Lengths | ||
Electrical Characteristics: | |||
Inner Conductor Resistance | The Max. at 20℃ shall be<13.1Ω/km | ||
Capacitance | 67±3 pF/m | ||
Impedance | 75 ± 3 Ω | ||
Return loss | between 5 and 1000MHz: > 20dB | ||
Velocity of Propagation | |||
Sparker Test (VAC) | 1 | ||
Mechanical and Envrionmental Properties | |||
Cable bend radius | 10 times the cable diameter | ||
Operating Temp Range | -20 ℃ to 65℃ | ||
Cable diamensions | |||
Cross Section | |||
| |||
Attenuation(20℃): | |||
Frequency (MHZ) | Max Attenuation(dB/100ft) | Max Attenuation (dB/100m) | |
10 | |||
30 | |||
72 | |||
88 | |||
90 | |||
135 | |||
180 | |||
220 | |||
270 | |||
440 | |||
750 | |||
770 | |||
1300 | |||
2400 | |||
Order Informations: | |||
Marking | HELLOSIGNAL 10C-2V CCTV COAXIAL CABLE 7100910 ×××M/FT | ||
Package | Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet … | ||
Delivery time | Normally 25 days after received the deposit. | ||
Brand | HELLOSIGNAL® OR OEM | ||
