NO.7100906 5C-2V

5C-2V

75 Ohm CCTV coaxial Cable

NO.7100906

■ Construction Parameters:

Inner Conductor:0.80mm BC

Dielectric:2.4mm SPE

Shield:0.14mm×7×24 BC Braid(L=42)

Jacket:7.6±0.5mmPVC

Jacket Thickness:0.09mm

Application:For Use in Longer CCTV Run Lengths

■ Electrical Characteristics:

Inner Conductor Resistance:The Max. at 20℃ shall be<35.9Ω/km

Capacitance:67±3 pF/m

Impedance:75 ± 3 Ω

Return loss:between 5 and 1000MHz: > 20dB

Velocity of Propagation:

Sparker Test (VAC):1

■ Mechanical and Environmental Properties:

Cable bend radius:10 times the cable diameter

Operating Temp Range:-20 ℃ to 65℃

■ Cross Section:

■ Attenuation(20℃):

■ Order Information:

Marking: HELLOSIGNAL 5C-2V     CCTV COAXIAL CABLE 7100906 ×××M/FT

Package: Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …

Delivery time: Normally 25 days after received the deposit.

Brand: HELLOSIGNAL® OR OEM
