NO.7100901 1.5C-2V

Construction Parameters:

Inner Conductor

0.26mm CCS

Dielectric

1.6mm SPE

Shield

0.10mm×5×16 BC Braid(L=16)

Jacket

2.9±0.4mmPVC

Jacket Thickness

0.04mm

Application

For Use in Longer CCTV Run Lengths

Electrical Characteristics:

Inner Conductor Resistance

The Max. at 20℃ shall be<968Ω/km

Capacitance

69±4 pF/m

Impedance

75 ± 3 Ω

Return loss

between 5 and 1000MHz: > 20dB

Velocity of Propagation

Sparker Test (VAC)

1

Mechanical and Envrionmental Properties

Cable bend radius

10 times the cable diameter

Operating Temp Range

-20 ℃ to 65℃

Cable diamensions

2.9±0.4mmPVC

Cross Section

Attenuation(20℃):

Frequency (MHZ)

Max Attenuation(dB/100ft)

Max Attenuation (dB/100m)

10

9.60

30

16.60

72

25.80

88

28.50

90

28.80

135

35.30

180

40.70

220

45.00

270

49.00

440

63.70

750

770

Order Informations:

Marking

HELLOSIGNAL 1.5C-2V

CCTV COAXIAL CABLE 7100901 ×××M/FT

Package

Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL® OR OEM
