3C-2VCS
hellosignal
7100904
Coaxial Cable
75 ohm
UL, ETL, CE, RoHS
100m, 305m,500m,1000m,500ft,1000ft
roll, wooden spool, carton, pallet
30KM
Normally 15 working days
NINGBO, SHANGHAI
T/T, L/C at sight, D/P at sight
75 Ohm CCTV coaxial Cable NO.7100904 | |||
Construction Parameters: | |||
Inner Conductor | 0.50mm CCS | ||
Dielectric | 3.1mm SPE | ||
Shield | 6×16×0.12mm BC | ||
Jacket | 5.4±0.5mmPVC | ||
Jacket Thickness | 0.08mm | ||
Application | For Use in Longer CCTV Run Lengths | ||
Electrical Characteristics: | |||
Inner Conductor Resistance | The Max. at 20℃ shall be<91.4Ω/km | ||
Capacitance | 67±3 pF/m | ||
Impedance | 75 ± 3 Ω | ||
Return loss | between 5 and 1000MHz: > 20dB | ||
Velocity of Propagation | |||
Sparker Test (VAC) | 1 | ||
Mechanical and Envrionmental Properties | |||
Cable bend radius | 10 times the cable diameter | ||
Operating Temp Range | -20 ℃ to 65℃ | ||
Cable diamensions | |||
Cross Section | |||
| |||
Attenuation(20℃): | |||
Frequency (MHZ) | Max Attenuation(dB/100ft) | Max Attenuation (dB/100m) | |
10 | 4.80 | ||
30 | 8.30 | ||
72 | 12.90 | ||
88 | 14.20 | ||
90 | 14.40 | ||
135 | 17.60 | ||
180 | 20.40 | ||
220 | 22.50 | ||
270 | 24.90 | ||
440 | 31.80 | ||
750 | 41.60 | ||
770 | 42.10 | ||
Order Informations: | |||
Marking | HELLOSIGNAL 3C-2VCS CCTV COAXIAL CABLE 7100904 ×××M/FT | ||
Package | Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet … | ||
Delivery time | Normally 25 days after received the deposit. | ||
Brand | HELLOSIGNAL® OR OEM | ||
75 Ohm CCTV coaxial Cable NO.7100904 | |||
Construction Parameters: | |||
Inner Conductor | 0.50mm CCS | ||
Dielectric | 3.1mm SPE | ||
Shield | 6×16×0.12mm BC | ||
Jacket | 5.4±0.5mmPVC | ||
Jacket Thickness | 0.08mm | ||
Application | For Use in Longer CCTV Run Lengths | ||
Electrical Characteristics: | |||
Inner Conductor Resistance | The Max. at 20℃ shall be<91.4Ω/km | ||
Capacitance | 67±3 pF/m | ||
Impedance | 75 ± 3 Ω | ||
Return loss | between 5 and 1000MHz: > 20dB | ||
Velocity of Propagation | |||
Sparker Test (VAC) | 1 | ||
Mechanical and Envrionmental Properties | |||
Cable bend radius | 10 times the cable diameter | ||
Operating Temp Range | -20 ℃ to 65℃ | ||
Cable diamensions | |||
Cross Section | |||
| |||
Attenuation(20℃): | |||
Frequency (MHZ) | Max Attenuation(dB/100ft) | Max Attenuation (dB/100m) | |
10 | 4.80 | ||
30 | 8.30 | ||
72 | 12.90 | ||
88 | 14.20 | ||
90 | 14.40 | ||
135 | 17.60 | ||
180 | 20.40 | ||
220 | 22.50 | ||
270 | 24.90 | ||
440 | 31.80 | ||
750 | 41.60 | ||
770 | 42.10 | ||
Order Informations: | |||
Marking | HELLOSIGNAL 3C-2VCS CCTV COAXIAL CABLE 7100904 ×××M/FT | ||
Package | Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet … | ||
Delivery time | Normally 25 days after received the deposit. | ||
Brand | HELLOSIGNAL® OR OEM | ||
