7C-2V
hellosignal
7100909
Coaxial Cable
75 ohm
UL, ETL, CE, RoHS
100m, 305m,500m,1000m,500ft,1000ft
roll, wooden spool, carton, pallet
30KM
Normally 15 working days
NINGBO, SHANGHAI
T/T, L/C at sight, D/P at sight
75 Ohm CCTV coaxial Cable NO.7100909 | |||
Construction Parameters: | |||
Inner Conductor | 7×0.40mmBC | ||
Dielectric | 7.3mmSPE | ||
Shield | 0.18mm×8×24 BC Braid(L=45) | ||
Jacket | 10.4±0.5mmPVC | ||
Jacket Thickness | 1.1mm | ||
Application | For Use in Longer CCTV Run Lengths | ||
Electrical Characteristics: | |||
Inner Conductor Resistance | The Max. at 20℃ shall be<20.7Ω/km | ||
Capacitance | 67±3 pF/m | ||
Impedance | 75 ± 3 Ω | ||
Return loss | between 5 and 1000MHz: > 20dB | ||
Velocity of Propagation | |||
Sparker Test (VAC) | 1 | ||
Mechanical and Envrionmental Properties | |||
Cable bend radius | 10 times the cable diameter | ||
Operating Temp Range | -20 ℃ to 65℃ | ||
Cable diamensions | |||
Cross Section | |||
| |||
Attenuation(20℃): | |||
Frequency (MHZ) | Max Attenuation(dB/100ft) | Max Attenuation (dB/100m) | |
10 | 1.70 | ||
30 | 2.90 | ||
72 | 4.60 | ||
88 | 5.00 | ||
90 | 5.10 | ||
135 | 6.20 | ||
180 | 7.20 | ||
220 | 8.00 | ||
270 | 8.80 | ||
440 | 11.30 | ||
750 | 14.60 | ||
770 | 14.80 | ||
1300 | 19.20 | ||
2400 | 26.10 | ||
Order Informations: | |||
Marking | HELLOSIGNAL 7C-2V CCTV COAXIAL CABLE 7100909 ×××M/FT | ||
Package | Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet … | ||
Delivery time | Normally 25 days after received the deposit. | ||
Brand | HELLOSIGNAL® OR OEM | ||
75 Ohm CCTV coaxial Cable NO.7100909 | |||
Construction Parameters: | |||
Inner Conductor | 7×0.40mmBC | ||
Dielectric | 7.3mmSPE | ||
Shield | 0.18mm×8×24 BC Braid(L=45) | ||
Jacket | 10.4±0.5mmPVC | ||
Jacket Thickness | 1.1mm | ||
Application | For Use in Longer CCTV Run Lengths | ||
Electrical Characteristics: | |||
Inner Conductor Resistance | The Max. at 20℃ shall be<20.7Ω/km | ||
Capacitance | 67±3 pF/m | ||
Impedance | 75 ± 3 Ω | ||
Return loss | between 5 and 1000MHz: > 20dB | ||
Velocity of Propagation | |||
Sparker Test (VAC) | 1 | ||
Mechanical and Envrionmental Properties | |||
Cable bend radius | 10 times the cable diameter | ||
Operating Temp Range | -20 ℃ to 65℃ | ||
Cable diamensions | |||
Cross Section | |||
| |||
Attenuation(20℃): | |||
Frequency (MHZ) | Max Attenuation(dB/100ft) | Max Attenuation (dB/100m) | |
10 | 1.70 | ||
30 | 2.90 | ||
72 | 4.60 | ||
88 | 5.00 | ||
90 | 5.10 | ||
135 | 6.20 | ||
180 | 7.20 | ||
220 | 8.00 | ||
270 | 8.80 | ||
440 | 11.30 | ||
750 | 14.60 | ||
770 | 14.80 | ||
1300 | 19.20 | ||
2400 | 26.10 | ||
Order Informations: | |||
Marking | HELLOSIGNAL 7C-2V CCTV COAXIAL CABLE 7100909 ×××M/FT | ||
Package | Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet … | ||
Delivery time | Normally 25 days after received the deposit. | ||
Brand | HELLOSIGNAL® OR OEM | ||
