Reference Standards Listed in the Datasheet
The BS 7629-1 Standard 60 entry lists BS 7629-1:2015, BS 6387:2013 (CWZ), EN 50200:2015 Annex E (30 mins), BS 5839-1:2013 Clause 26.2d standard, EN / IEC 60754-1:2014 for acidity, and EN / IEC 61034-2:2005+A1:2013 for smoke density.
Construction Details
The cable uses plain annealed copper wire Class 5 stranded flexible conductors, special mix silicone rubber insulation, PET foil with more than 120% coverage as first screen, tinned copper drain wire with OD 0.80 mm, aluminum polyester tape with more than 120% coverage as second screen, and thermoplastic low smoke halogen free outer sheath.
| Block | Catalog Detail | Selection Meaning |
|---|---|---|
| Conductors | Plain annealed copper wire, Class 5 STR flexible | Supports flexible routing and installation handling. |
| Insulation | Special mix silicone rubber | Part of the fire cable construction. |
| Screens | PET foil and aluminum polyester tape | Screened construction with drain wire. |
| Sheath | Thermoplastic low smoke halogen free | Supports low smoke and halogen-free material requirements. |
Electrical and Installation Data
The entry lists insulation resistance above 200 M Ohm*Km, 2000 V / 2000 V core-core/core-screen test voltage, mutual capacitance below 150 nF/km, operating voltage of 300/500 V, operation from -30℃ up to +180℃, installation from -5℃ up to +50℃, and minimum bending radius of 8× cable diameter.
When to Discuss This Family With ZION
Discuss BS 7629-1 Standard 60 when the project specification names this standard family or related BS 5839 Clause 26.2d context. Send the core count, cross section, sheath color, cable length, printing, packing, and any required approval documentation.
FAQ
Is BS 7629 Standard 60 the same as EN 50200 PH120?
No. They are different references. The Standard 60 datasheet lists its own standard context and also references EN 50200 Annex E for 30 minutes.
What conductor class does the ZION Standard 60 entry use?
The catalog entry lists Class 5 stranded flexible conductors.
What sheath material is listed?
The datasheet lists thermoplastic low smoke halogen free outer sheath.
