| Image | Product Name | Inquiry | Add to basket |
|---|---|---|---|
 | FC UPC to FC UPC Simplex G.652.D Single Mode PVC 2.0mm -2m(6ft) FOPC | Inquire | Add to Basket |
 | LC UPC to FC UPC Simplex G.652.D Single Mode PVC 2.0mm -2m(6ft) FOPC | Inquire | Add to Basket |
| Fiber Type | Single-mode: OS2 ( G.652.D / G.657.A1 / G.657.A2) | |
| Multi-mode: OM1(62.5/125), OM2(50(125), [(OM3, OM4) (50/125,Laser Optimization)] | ||
| Fiber Count | Simplex / Duplex | |
| Cable Jacket | Main material: PVC / LSZH / Plenum (OFNP) | |
| OD: Simplex: 0.9/2.0/3.0mm Duplex: 0.9/2.0/3.0mm | ||
| Jacket Color | Yellow: SM: OS2 ( G.652.D / G.657.A1 / G.657.A2) | |
| Orange: OM1, OM2 | ||
| Aqua: OM3, OM4 | ||
| Cable Length | 1m, 2m, 3m. other lengths on request | |
| Mechanical Specification | Ferrule | Ceramic; (MTRJ: PS-Polyphenylene Sulphide) |
| Apex Offset | ＜ 50um | |
| Fiber Height | ± 100nm | |
| Radius of Curvature | 7mm R ＜ 25mm (Excluding MTRJ) | |
| Parameter | FC/SC/LC | ST/MU/MTRJ | |||
| SM(OS2) | MM | SM | MM | ||
| UPC | APC | UPC/APC | UPC | UPC | |
| Operating Wavelength(nm) | 1310-1550 | 850-1300 | 1310-1550 | 850-1300 | |
| Insertion Loss (dB) | ≤ 0.3 | ≤ 0.3 | ≤ 0.3 | ≤ 0.3 | ≤ 0.3 |
| Return Loss (dB) | ≥ 55 | ≥ 60 | ≥ 35 | ≥ 50 | ≥ 35 |
| Repeatability (dB) | ≤ 0.1 | ≤ 0.1 | ≤ 0.1 | ≤ 0.1 | ≤ 0.1 |
| Interchangeability (dB) | ≤ 0.2 | ≤ 0.2 | ≤ 0.2 | ≤ 0.2 | ≤ 0.2 |
| Tensil Strength (N) | ≥ 1000 | ≥ 1000 | ≥ 1000 | ≥ 1000 | ≥ 1000 |
| Operating Temperature (℃） | -20 ~ +85 | -20 ~ +85 | -20 ~ +85 | -20 ~ +85 | -20 ~ +85 |
| Storage Temperature (℃） | -40 ~ +85 | -40 ~ +85 | -40 ~ +85 | -40 ~ +85 | -40 ~ +85 |
