G28 Coaxial Cable 75 Ohm CCTV coaxial Cable

Construction Parameters:

Inner Conductor

0.58+ / -0.01mmCCS

Dielectric

0.75+ / -0.05mm OD(4.5/3.0) LDPE

Shield

16x6x 0.1+ / -0.01mm
 (70% Coverage)Tinned Copper

Jacket

6.0+ / -0.15mm Black UV Rated

Application

For Use in Longer CCTV Run Lengths

Electrical Characteristics:

Inner Conductor Resistance

Capacitance

Impedance

Return loss

Velocity of Propagation

Sparker Test (VAC)

Mechanical and Envrionmental Properties

Cable bend radius

10 times the cable diameter

Operating Temp Range

Cable diamensions

Cross Section

Attenuation(20℃):

Frequency (MHZ)

Max Attenuation(dB/100ft)

Max Attenuation (dB/100m)

5

55

100

211

300

500

750

870

1000

1450

1750

2150

Order Informations:

Marking

HELLOSIGNAL G28 Coaxial Cable

CCTV COAXIAL CABLE 7100471 ×××M/FT

Package

Inquired Length on Reel,wooden Spool,pallet …

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL^® OR OEM
