NO.7100307 Паракс РК 75-2-13M BC 88% CCA PVC

Construction Parameters:

Inner Conductor

0.005"/7*0.12mm/36 AWG BC

Dielectric

0.144"/2.2mm  Solid PE

Shield

Copper clad aluminum
braid wire 88% coverage

Jacket

0.130"±0.006"/3.30±0.30mm PVC

Jacket Thickness

0.032"/0.81mm

Application

For Use in Longer CCTV Run Lengths

Electrical Characteristics:

Inner Conductor Resistance

The Max. at 20℃ shall be < 168.2 Ω/km

Capacitance

68±1 pF/m

Impedance

75±5 Ω

Return loss

20dB

Velocity of Propagation

Sparker Test (VAC)

Mechanical and Envrionmental Properties

Cable bend radius

10 times the cable diameter

Operating Temp Range

-20 ℃ to 60℃

Cable diamensions

0.130"±0.006"/3.30±0.30mm PVC

Cross Section

Attenuation(20℃):

Frequency (MHZ)

Max Attenuation(dB/100m)

10

6.56

50

14.60

200

30.60

470

46.80

862

64.50

1000

70.10

1350

82.90

1750

95.20

2150

107.00

2400

117.00

Order Informations:

Marking

HELLOSIGNAL PK75-2-13M BC 88% CCA PVC

 CCTV COAXIAL CABLE 7100307 ×××M/FT

Package

Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL® OR OEM
