NO.7100309 Паракс РК 75-2-111 BC 40% CCA PE

  • Паракс РК 75-2-111

  • hellosignal

  • 7100309

  • Coaxial Cable

  • 75 ohm

  • UL, ETL, CE, RoHS

  • 100m, 305m,500m,1000m,500ft,1000ft

  • roll, wooden spool, carton, pallet

  • 30KM

  • Normally 15 working days

  • NINGBO, SHANGHAI

  • T/T, L/C at sight, D/P at sight

Availability:

Specification

zion LOGOPK75-2-111 BC 40% CCA PE

75 Ohm CCTV coaxial Cable

NO.7100309

Construction Parameters:

Inner Conductor

0.014"/0.37mm/28 AWG BC

Dielectric

0.144"/2.2mm  Solid PE

Shield

Copper clad aluminum
braid wire 40% coverage

Jacket

0.148"±0.006"/3.80±0.30mm PE

Jacket Thickness

0.032"/0.81mm

Application

For Use in Longer CCTV Run Lengths

Electrical Characteristics:

Inner Conductor Resistance


The Max. at 20 shall be < 168.2 Ω/km

Capacitance

68±1 pF/m


Impedance

75±5 Ω

Return loss


Velocity of Propagation


Sparker Test (VAC)



Mechanical and Envrionmental Properties

Cable bend radius

10 times the cable diameter

Operating Temp Range

-20  to 60 / -40  to 80

Cable diamensions

0.148"±0.006"/3.80±0.30mm PE


Cross Section


Attenuation(20℃):

Frequency (MHZ)

Max Attenuation(dB/100m)


10

5.86


50

13.50


200

30.80


470

47.50


862

73.00


1000



1350



1750




Order Informations:

Marking

HELLOSIGNAL PK75-2-111 BC 40% CCA PE

CCTV COAXIAL CABLE 7100309 ×××M/FT

Package

Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL® OR OEM
