Паракс РК 75-2-122
hellosignal
7100314
Coaxial Cable
75 ohm
UL, ETL, CE, RoHS
100m, 305m,500m,1000m,500ft,1000ft
roll, wooden spool, carton, pallet
30KM
Normally 15 working days
NINGBO, SHANGHAI
T/T, L/C at sight, D/P at sight
75 Ohm CCTV coaxial Cable NO.7100314 | |||
Construction Parameters: | |||
Inner Conductor | 0.014"/0.37mm/28 AWG BC | ||
Dielectric | 0.144"/2.2mm Solid PE | ||
Shield 1 | Al/PET | ||
Shield 2 | Copper braid wire 45% coverage | ||
Jacket | 0.130"±0.006"/3.30±0.30mm PE | ||
Jacket Thickness | 0.032"/0.81mm | ||
Application | For Use in Longer CCTV Run Lengths | ||
Electrical Characteristics: | |||
Inner Conductor Resistance | The Max. at 20℃ shall be < 168.2 Ω/km | ||
Capacitance | 68±1 pF/m | ||
Impedance | 75±5 Ω | ||
Return loss | 20dB | ||
Velocity of Propagation | |||
Sparker Test (VAC) | |||
Mechanical and Envrionmental Properties | |||
Cable bend radius | 10 times the cable diameter | ||
Operating Temp Range | -20 ℃ to 60℃ / -40 ℃ to 80℃ | ||
Cable diamensions | 0.130"±0.006"/3.30±0.30mm PE | ||
Cross Section | |||
| |||
Attenuation(20℃): | |||
Frequency (MHZ) | Max Attenuation(dB/100m) | ||
10 | 6.40 | ||
50 | 12.70 | ||
200 | 24.00 | ||
470 | 37.60 | ||
862 | 52.10 | ||
1000 | 56.70 | ||
1350 | 65.60 | ||
1750 | 76.80 | ||
2150 | 85.80 | ||
2400 | 97.90 | ||
Order Informations: | |||
Marking | HELLOSIGNAL PK75-2-122 BC 45% CCA PE CCTV COAXIAL CABLE 7100314 ×××M/FT | ||
Package | Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet … | ||
Delivery time | Normally 25 days after received the deposit. | ||
Brand | HELLOSIGNAL® OR OEM | ||
75 Ohm CCTV coaxial Cable NO.7100314 | |||
Construction Parameters: | |||
Inner Conductor | 0.014"/0.37mm/28 AWG BC | ||
Dielectric | 0.144"/2.2mm Solid PE | ||
Shield 1 | Al/PET | ||
Shield 2 | Copper braid wire 45% coverage | ||
Jacket | 0.130"±0.006"/3.30±0.30mm PE | ||
Jacket Thickness | 0.032"/0.81mm | ||
Application | For Use in Longer CCTV Run Lengths | ||
Electrical Characteristics: | |||
Inner Conductor Resistance | The Max. at 20℃ shall be < 168.2 Ω/km | ||
Capacitance | 68±1 pF/m | ||
Impedance | 75±5 Ω | ||
Return loss | 20dB | ||
Velocity of Propagation | |||
Sparker Test (VAC) | |||
Mechanical and Envrionmental Properties | |||
Cable bend radius | 10 times the cable diameter | ||
Operating Temp Range | -20 ℃ to 60℃ / -40 ℃ to 80℃ | ||
Cable diamensions | 0.130"±0.006"/3.30±0.30mm PE | ||
Cross Section | |||
| |||
Attenuation(20℃): | |||
Frequency (MHZ) | Max Attenuation(dB/100m) | ||
10 | 6.40 | ||
50 | 12.70 | ||
200 | 24.00 | ||
470 | 37.60 | ||
862 | 52.10 | ||
1000 | 56.70 | ||
1350 | 65.60 | ||
1750 | 76.80 | ||
2150 | 85.80 | ||
2400 | 97.90 | ||
Order Informations: | |||
Marking | HELLOSIGNAL PK75-2-122 BC 45% CCA PE CCTV COAXIAL CABLE 7100314 ×××M/FT | ||
Package | Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet … | ||
Delivery time | Normally 25 days after received the deposit. | ||
Brand | HELLOSIGNAL® OR OEM | ||
PK75-2-122 BC 45% BC PE
