NO.7100363 Паракс РК 75-3-322 TCCA LSZH

  • Паракс РК 75-3-322

  • hellosignal

  • 7100363

  • Coaxial Cable

  • 75 ohm

  • UL, ETL, CE, RoHS

  • 100m, 305m,500m,1000m,500ft,1000ft

  • roll, wooden spool, carton, pallet

  • 30KM

  • Normally 15 working days

  • NINGBO, SHANGHAI

  • T/T, L/C at sight, D/P at sight

Availability:

Specification

zion LOGOPK75-3-322  PK75-3-312 TCCA LSZH

75 Ohm CCTV coaxial Cable

NO.7100363

Construction Parameters:

Inner Conductor

0.024"/0.60mm/22 AWG BC

Dielectric

0.144"/2.70mm FPE

Shield 1

AL/Pet Foil

Shield 2

0.12mmTCCA(51%)Braiding

Jacket

0.170"±0.006"/4.50±0.30mm LSZH

Jacket Thickness

0.032"/0.81mm

Application

For Use in Longer CCTV Run Lengths

Electrical Characteristics:

Inner Conductor Resistance


The Max. at 20 shall be < 63Ω/km

Capacitance

56.5±1 pF/m


Impedance

75±5 Ω

Return loss

between 5 and 1000MHz: > 20dB

Velocity of Propagation

0.82

Sparker Test (VAC)



Mechanical and Envrionmental Properties

Cable bend radius

10 times the cable diameter

Operating Temp Range

-20  to 60

Cable diamensions

0.130"±0.006"/3.30±0.30mm LSZH


Cross Section


Attenuation(20℃):

Frequency (MHZ)

Max Attenuation(dB/100m)


10

3.51


50

7.50


200

15.50


470

24.20


862

33.30


1000

36.30


1350

42.70


1750

49.60


2150

54.90


2400

58.60



Order Informations:

Marking

HELLOSIGNAL PK75-3-322  PK75-3-312 TCCA LSZH

CCTV COAXIAL CABLE 7100363 ×××M/FT

Package

Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL® OR OEM
