NO.7102209 КВК-В-2Э+2х0.75, Figure 8

  • КВК-В-2Э

  • hellosignal

  • 7102209

  • Coaxial Cable

  • 75 ohm

  • UL, ETL, CE, RoHS

  • 100m, 305m,500m,1000m,500ft,1000ft

  • roll, wooden spool, carton, pallet

  • 30KM

  • Normally 15 working days

  • NINGBO, SHANGHAI

  • T/T, L/C at sight, D/P at sight

Availability:

Specification

zion LOGOКВК-В-2Э+2х0.75, Figure 8

75 Ohm CCTV coaxial Cable

NO.7102209

Construction Parameters:

Inner Conductor

0.37mmCu

Dielectric

2.3mm Solid Polyethylene

Shield

32×0.12mmCCA(45%)

Jacket

3.8mm PVC

Power Wire Conductor

2x(16x0.25mmCCA )

Power wire Diameter of insulation

2.0mm PVC (Red,Black)

Jacket

5.0mm PVC Common

Application

For Use in Longer CCTV Run Lengths

Electrical Characteristics:

Inner Conductor                         Resistance

The Max. at 20 shall be <  166.48 Ω/km

Capacitance

68±1 pF/m


Impedance

75±5 Ω

Return loss

20dB

Velocity of Propagation

0.66

Sparker Test (VAC)

3



Mechanical and Envrionmental Properties

Cable bend radius

10 times the cable diameter

Operating Temp Range

-20  to 60

Cable diamensions

3.8×5.0mm



Cross Section

NO.7102208

Attenuation(20℃):

Frequency (MHZ)

Max Attenuation(dB/100ft)

Max Attenuation (dB/100m)

5


3.69

50


11.62

100


16.50

300


28.42

450


34.81

865


48.25

1000


51.88

1750


68.62

2150


76.06

2500


82.01

3000


89.84

















Order Informations:

Marking

HELLOSIGNAL КВК-В-2Э+2х0.75, Figure 8
CCTV COAXIAL CABLE 7102209 ×××M/FT

Package

Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL®OR OEM
