NO.7110342 18AWG 2/C STR Shielded FPLP-CL2P Fire Alarm Cables

Cable construction :

Conductor:

18AWG Stranded Bare Copper

18 AWG : 7/26, 16/30, 19/30, 41/34, 65/36

Nom.Dia:0.04''(1.02mm)

Dielectric:

Type: Plenum PVC

Dia.over Dielectric: 0.0618±0.004''nom.(1.57±0.10mm)

Drain Wire: 0.51mm Solid Tinned-Copper

Shield :0.001"(0.025mm) thick Aluminum/Mylar

Color Code:

1.Blk

2.Red

Jacket:

Type: Plenum PVC

Color: Red

Dia.over Jacket: 0.156"±0.006''(3.97±0.15mm)

Print Legend:

HELLOSIGNAL NO.7110342 18AWG 2C 75C E××××××(UL) STR Shielded FPLP-CL2P

SUN RES(ROHS) ××××M/FT DEVICE/ZONEA B C D E F 1 2 3 4 5 6 7 8 9

Electrical Properties :

Temperature Rating

-20℃ ~ +75℃

Operating Voltage

300 Volts max

Capacitance

42 pf/ft nom

Impedance

36 Ohms nom

DC Resistance

6.5 Ohms/M' at 20℃

Cross Section :

Order Informations :

Package

Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL^® OR OEM
