FRLS & FRFH Fire alarm cable
hellosignal
7110573
Fire Alarm Cable
UL, ETL, CE,CPR, RoHS
100m,500m,500ft,1000ft
roll, wooden spool, carton, pallet
10KM
Normally 15 working days
NINGBO, SHANGHAI
T/T, L/C at sight, D/P at sight
КПСЭ нг(А)-FRFH 4×0.75mm² shielded Fire Alarm Cable NO.7110569 | ||
Cable construction : | ||
Conductor: | Bare copper class 1 4×0.96mm | |
Insulation: | Type: Silicone Dia.over Dielectric: 0.086''nom.(2.2mm) | |
Insulation Color: | Blu/Brn/Blk/Gry | |
Separator : | PET Foil | |
Drain Wire: | 0.4 mm Solid tinned copper | |
Shield: | Aluminum PET (100% Coverage 20% overlapping) | |
Jacket: | FRFH-LSOH | |
Dia.over Jacket: 0.270''(6.85mm) | ||
Print Legend: | ||
HELLOSIGNAL NO.7110569 КПСЭ нг(А)-FRFH 4×0.75mm² shielded Cable MMDDYYYY | ||
Electrical Properties : | ||
Minimum Bend Radius | 8×Diameter | |
Min.DC resistance | 25.5 ohm/KM | |
Min.Insulation resistance | 100 MΩ/km | |
Installation Temperature | -10℃～+50℃ | |
Test voltage (rms value) | 1000V | |
Max. Operating Voltage | 300 V | |
Cross Section : | ||
| ||
Test Standards | ||
√180 minutes under fire of 750 degrees without short-circuit. | ||
√Fire hazard class of the cable on the classification of ГОСТ Р 31565-2012 - P1.1.2.2.2. | ||
√Cable flame retardant while installing in category A (ГОСТ Р IEC 60332-3-22-2005). | ||
√Indicator toxicity of the combustion products of polymeric material of the cable - not less than 41g / m. | ||
√Smoke generation during combustion and smoldering cable does not reduce the light transmittance of more than 50% (GOST R IEC 61034-2-2005). | ||
√The cable is designed for fixed installation for voltage to 300 V AC to 10 kHz or 420 VDC. | ||
Order Informations : | ||
Package | 100M/Reel,200M/Reel,500M/Wooden Spool | |
Delivery time | Normally 25 days after received the deposit. | |
Brand | HELLOSIGNAL® OR OEM | |
