Product Description
20×0.2mm² SOL-S Security Alarm Cable NO.7111058 | ||||
Cable construction : | ||||
Conductor: |
| |||
20 x (1/0.50mm) TC/BC/CCA/TCCA | ||||
Dielectric: | ||||
Type: PVC | ||||
Diameter: 0.95mm | ||||
Color Code: | ||||
1.Blk | 2.Red | 3.Ylw | 4.Grn | |
5.Brn | 6.Blu | 7.Wht | 8.Org | |
9.Ppl | 10.Gry | 11.Pnk | 12.Tan | |
13.Wht/Brn | 14.Wht/Ppl | |||
15.Wht/Grn | 16.Wht/Blu | |||
17.Wht/Gry | 18.Wht/Ylw | |||
19.Wht/Blk | 20.Wht/Red | |||
Shield: | ||||
Aluminum Foil | ||||
Rip Cord | ||||
Cotton Wire | ||||
Jacket: | ||||
Type: PVC | ||||
Diameter: 7.30mm | ||||
Application: | ||||
Wiring Burglar & Security alarms, public address systems,intercoms, telephone stations, | ||||
Print Legend: | ||||
HELLOSIGNAL NO.7111058 0.2mm² Solid 20C Shielded Security Alarm Cable ××× M | ||||
Cross Section : | ||||
 | ||||
Order Informations : | ||||
Package | Inquired Length on Reel,Pull Box,Plastic Spool,Wooden Spool,Pallet … | |||
Delivery time | Normally 25 days after received the deposit. | |||
Brand | HELLOSIGNALTM OR OEM | |||
Production Process Flow
