NO.7111262 2×0.75+4×0.22mm² STR-S

2×0.75+4×0.22mm² STR-S
Security Alarm Cable
NO.7111262

Cable construction :

Party 1

Conductor:

2×(24/0.20mm)TC/BC/CCA/TCCA

Dielectric:

Type: PVC

Diameter: 1.80mm

Color Code:

1.Blk

2.Red

Party 2

Conductor:

4×(7/0.20mm)TC/BC/CCA/TCCA

Dielectric:

Type: PVC

Diameter: 0.95mm

Color Code:

1.Blk

2.Red

3.Ylw

4.Grn

Drain Wire

7x0.20mm TC/BC/CCA/TCCA

Shield:

Aluminum Foil

Rip Cord

Cotton Wire

Jacket:

Type: PVC

Diameter: 5.0mm

Print Legend:

HELLOSIGNAL NO.7111262 2×0.75+4×0.22mm² STR-S Security Alarm Cable ××× M

Application:

    Wiring Burglar & Security alarms, public address systems,intercoms, telephone stations,
    speakers,instrumentation,control and other low voltage circuits that are power limited.

Cross Section :

Order Informations :

Package

Inquired Length on Reel,Pull Box,Plastic Spool,Wooden Spool,Pallet …

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL^TM OR OEM
