Security Cable shielded
hellosignal
7111391
security alarm cable
UL, ETL, CE,CPR, RoHS
100m,305m,500m,500ft,1000ft
pull box, wooden spool, carton, pallet
10KM
Normally 25 working days
NINGBO, SHANGHAI
T/T, L/C at sight, D/P at sight
12/2 STR-S | ||||
Cable construction : | ||||
Conductor: |
| |||
(12AWG 19/0.0185 " Stranded Bare Copper) X 2 | ||||
Nom.Dia:0.081''(2.05mm) | ||||
Dielectric: | ||||
Type: Polypropylene | ||||
Dia.over Dielectric: 0.114''(2.9mm) | ||||
Color Code: | ||||
1.Blk | 2.Red | |||
Shield: | ||||
0.038mmAlum/Mylar tape | ||||
Wire | ||||
Rip Cord | ||||
Jacket: | ||||
Type: PVC | ||||
Dia.over Jacket: 0.280''(7.13mm) | ||||
Electrical Properties : | ||||
Temperature Rating | （-20℃ ~ +60℃） | |||
Operating Voltage | ||||
Capacitance | ||||
Impedance | ||||
DC Resistance | ||||
Print Legend: | ||||
HELLOSIGNAL NO.7111391 12/2 STR-U 2C E××××××(UL) Shielded PVC SUN RES(ROHS) ××××M/FT DEVICE/ZONE A B C D E F 1 2 3 4 5 6 7 8 9 | ||||
Cross Section : | ||||
| ||||
Order Informations : | ||||
Package | Inquired Length on Reel,Pull Box,Plastic Spool,Wooden Spool,Pallet … | |||
Delivery time | Normally 25 days after received the deposit. | |||
Brand | HELLOSIGNALTM OR OEM | |||
