Author: James Publish Time: 08-07-2025 Origin: Site
Zion Communication is an ADSS Cable Manufacturer in China with unquestionable quality and high reliability.
With the worldwide demand for speedy, directable, and interference-free communications escalating, ADSS cables as a property of electric utilities and telecom networks have gained momentum. Deliberating on a beneficial ADSS manufacturer with extensive experience providing the right solution is of the essence to ensure long-term performance and safety.
Zion Communication, with headquarters located in Hangzhou, China, is an industry-leading provider and exporter of ADSS fiber optic cables. The company has more than two decades of accumulated experience in the field. Here, we offer full services, including Research and Development (R&D), cable production, quality evaluation, and Original Equipment Manufacturer (OEM) and Original Design Manufacturer (ODM), for clients worldwide in more than 60 countries.
ADSS is the abbreviated form of the All-Dielectric Self-Supporting fiber optic cable, which is meant exclusively for overhead power transmission and telecom networks, using non-metallic strength members (which eliminates the need for the use of steel ropes for support).
✓ All-dielectric: Non-conductive and safe close to high-voltage lines
✓ Self-supporting: Hangs directly between poles or towers
✓ Weather-resistant: Built to handle wind, UV, rain, and ice
✓ Long-span capability: Up to 700 meters or more
✓ Corrosion-free: Ideal for coastal or industrial areas
Power grids, telecom backbones, railways, pipelines, and smart infrastructure.
Zion Communication is a fully manufacturer-initiated factory based in China and possessed of the following advantages:
All production activities, from fiber selection to cable sheathing, take place at our Hangzhou factory. As a result, we ensure the maximum quality of our ADSS cables and exceptionally short production deadlines.
Our ADSS cables are designed on the basis of actual working conditions. Therefore:
Span length: 50m up to 700m
Wind & Ice Load: Based on IEC60794 & ASTM standards
Voltage Environment: 10kV to 220kV+
Jacket: PE for low voltage, AT (anti-tracking) for high voltage
Fiber Options: G.652D / G.657A / G.655, etc.
Manufacturing according to customers' requests
Offering a variety of colors for the outer sheath, printing, and length marking for your cable
Manufacturing customized boxes and brochures for your branding solutions
Providing complete accessories batch for your installations
We export to countries such as Vietnam, Kenya, and South Africa, as well as in Brazil, the UAE, Poland, and the Philippines.
Incoterms supported: FOB / CIF / DDP
The general structure includes:
Main Parts:
Centrally Positioned Central Strength Member: Constant-strength-FRP rod for tensile efficiency
Hollow Tubes: Moisture exclusion device for the ingress of water
Water-Blocking Yarn: Vertical direction, water retention-free
Aramid Yarn (Kevlar): Strength for biological aerial installations
Outer Jacket:
<Limited to less than 110 kV - PE insulator>
<At least 110 kV and polluted areas - AT insulator>
Environmental Durability
Temperature: -40°C ~ +70°C
UV, wind, ice, and corrosion-resistant
Expected lifetime: ≥25 years under outdoor exposure
Product Model | Fiber Count | Span | Jacket | Application |
ZC-ADSS-24F-120M | 24 cores | 120m | PE | Rural telecom / utility lines |
ZC-ADSS-48F-300M | 48 cores | 300m | AT | Medium-voltage corridor |
ZC-ADSS-96F-500M | 96 cores | 500m | AT | Power grid / long-distance transmission |
ZC-ADSS-12F-80M | 12 cores | 80m | PE | Short spans / railway routes |
Custom design available for:
2F to 144F fiber counts
G.652D, G.657A1, G.655
Flame-retardant / rodent-proof / LSZH jackets
Parameter | Specification |
Tensile Strength | 1.5kN ~ 15kN |
Bending Radius | ≥10× cable diameter |
Crush Resistance | ≥220N/100mm |
Water Penetration | No water ingress (24 hrs) |
Attenuation | ≤0.35 dB/km (1310nm), ≤0.22 dB/km (1550nm) |
Sheath Printing | Custom (length, model, date, logo) |
Electric Power Transmission Lines
Telecommunication and FTTH Backbones
Railway Signaling Systems
Oil and Gas Field Monitoring
Smart City Infrastructure
ADSS cable is suitable for forested areas, mountain, and coastal territories.
Zion additionally supplies correspondent apparatuses which stand for complete system supervision:
Suspension Clamps
Tension Clamps
Armor Rods
Downlead Clamps
Vibration Dampers
Preformed Grips & Anchoring Hardware
All accessories are prepared for testing for their mechanical ability, corrosion resistance, and voltage insulating qualities.
Feature | Zion Communication |
Factory Location | Hangzhou, China |
Industry Experience | 20+ years |
Export Destinations | 60+ countries |
Daily Output | 30,000+ meters |
OEM/ODM Capability | ✅ Full support |
Certifications | ISO9001, RoHS, CE |
Fiber Brands | YOFC, Corning, Futong |
MOQ | Flexible / Trial Orders Welcome |
Whether you’re an EPC contractor, telecom integrator, or local distributor, we hope Zion Communication will be your partner for ADSS cable projects Supremacy.
Request for the free datasheet, technical consultation, or quote from us today!
James is a technical manager and associate at Zion Communication.
Specializes in Optical Fiber communications, FTTH Solutions,
Fiber optic cables, ADSS cable, and ODN networks.
