FTP CAT5E 5E 4P+2/0.75mm2 | ||||||||||
Construction Parameters: | ||||||||||
Description | 4 Pair Cat5E Type + 2C-0.75 FIG.8 Construction | |||||||||
Video and Control Pairs | ||||||||||
Inner Conductor | 0.50mm/24AWG CCA | |||||||||
Stranding | Solid | |||||||||
Insulation Material | Polyethylene 0.2mm | |||||||||
Number of Conductors | 8(4 Pair) | |||||||||
Drain wire | TCCS | |||||||||
Shield | Aluminum/PET Foil | |||||||||
Power Conductors | ||||||||||
Inner Conductor | Copper Clad Aluminum | |||||||||
Stranding | 16×0.25mm | |||||||||
Insulation Material | PVC 0.2mm | |||||||||
Number of Conductors | 2 | |||||||||
Shield | None | |||||||||
Electrical Characteristics: | ||||||||||
Video and Control Pairs | ||||||||||
Temperature Rating | -20℃ to 60℃ | |||||||||
Operating Voltage | 300 V RMS | |||||||||
Max.Capacitance @1 KHz | 45.9 pf/100m | |||||||||
Nom.Impedance | 100 Ohms | |||||||||
Nom.Velocity of Propagation | 0.66 | |||||||||
DC Resistance per Cond. @ 20℃ | 26 Ohms/1M' Nom | |||||||||
Power Conductors | ||||||||||
Temperature Rating | -20℃ to 60℃ | |||||||||
Operating Voltage | 300 V RMS | |||||||||
Max.Capacitance @1 KHz | NA | |||||||||
DC Resistance per Cond. @ 20℃ | ||||||||||
Insulation Colors | Black, Red | |||||||||
Overall Construction | ||||||||||
Jacket Type | UV-PE | |||||||||
Jacket Color | Siamese-Black | |||||||||
Nom.O.D. | 5.4mm × 4.8mm | |||||||||
Mechanical Properties | ||||||||||
Max.Recommended Pull Tension | 15 KGS | |||||||||
Min. Bend Radius(Install) | 86mm | |||||||||
Order Informations: | ||||||||||
Marking | HELLOSIGNAL Video Over UTP 4 Pair FTP Cat5E E+ 2C-0.75MM2 FIG.8 | |||||||||
Inner Package | 500FT/PULL BOX, 1000FT/Wooden Spool,Pallet | |||||||||
Delivery time | Normally 20-25 days after received the deposit. | |||||||||
Brand | HELLOSIGNAL® OR OEM | |||||||||
