HELLOSIGNAL Z-SERVO PUR flexible screened control cable for servo motor

  • Z-SERVO PUR flexible screened control cable for servo motor
  • hellosignal
  • 7146020
Quantity:

Z-SERVO  PUR flexible,
screened control cable for servo motor

Application

Apply to high-speed,middle and high--end servo motor.
Be used as power wire in automation system.
Be used as connecting cables for power system of machine tool.
Resistant to hydrolysis and microbial attack.

Cable Construction

Conductor:high bending strength ultra-fine stranded copper conductor

Insulation:high mechanical strength TPE mixture

Core identification:power wires:one is yellow/green insulated wwire,others

      are white insulated wire print black font;A pair of singal wires:blue,red

Shield:high strength tinned copper braid

Jocket:high abrasion resistant PUR jacket.Orange(simllar to RAL2003)

Product Feature

This product meets the requirements of UL758 style 20939

Fire resistance meets FT1&IEC60332-1

Extremely oil resistance,anti-hydrolysis

Good performance of resistant to signal interference

High tensile strength,abrasion,impact and bending resistant

Cross Section

Z-SERVO PUR flexible,

Technical data

Temperature range

Bend:  -30 to 80

Static: -40 to 80

Rated voltage

UL/CSA    300V

 IEC/VDE   ≤0.5mm²;300/300V

                  ≥0.5mm²;450/750V

Insulation resistance

20≥1000M ohm/km

Min bending radius

Fixed 3D(D=cable diameter)

Moving: 7.5(D=cable diameter)

Product List

Item No.

Spec.(core*Nominal cross-section)
mm²

Nominal
OD(mm)

Copper.weight approx (kg/km)

Weight approx(kg/km)

7146020

(4G*0.75+(2*0.5)D)D

9.4

75

131

7146021

(4G*1.5+(2*1.5)D)D

11.1

139

212

7146022

(4G*2.5+(2*1.5)D)D

12.5

180

274

7146023

(4G*4.0+(2*1.5)D)D

15.4

264

400

7146024

(4G*6.0+(2*1.5)D)D

16.9

348

504

7146025

(4G*10+(2*1.5)D)D

20.8

519

773

7146026

(4G*16+(2*1.5)D)D

23.6

790

1096

7146027

(4G*25+(2*1.5)D)D

27.7

1162

1594

7146028

(4G*35+(2*1.5)D)D

32

1551

2128

Order Informations

Marking

HELLOSIGNAL Z-SERVO  PUR flexible,
screened control cable for servo motor XXXFT/M

Package

100M/Reel, 300M/Wooden Spool

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL® OR OEM
