NO.7100301 Паракс РК 75-2-110 BC 40% CCA PE

Construction Parameters:

Inner Conductor

0.014"/0.37mm/28 AWG BC

Dielectric

0.144"/2.2mm  Solid PE

Shield

0.12mm Copper clad aluminum
braid wire 40% coverage

Jacket

0.130"±0.006"/3.30±0.30mm PE

Jacket Thickness

0.032"/0.81mm

Application

For Use in Longer CCTV Run Lengths

Electrical Characteristics:

Inner Conductor Resistance

The Max. at 20℃ shall be < 168.2 Ω/km

Capacitance

68±1 pF/m

Impedance

75±5 Ω

Return loss

20dB

Velocity of Propagation

Sparker Test (VAC)

Mechanical and Envrionmental Properties

Cable bend radius

10 times the cable diameter

Operating Temp Range

-20 ℃ to 60℃ / -40 ℃ to 80℃

Cable diamensions

0.130"±0.006"/3.30±0.30mm PVC

Cross Section

Attenuation(20℃):

Frequency (MHZ)

Max Attenuation(dB/100m)

10

5.86

50

13.50

200

30.80

470

47.50

862

73.00

1000

1350

1750

Order Informations:

Marking

HELLOSIGNAL PK75-2-110 BC 40% CCA PE

 CCTV COAXIAL CABLE 7100301 ×××M/FT

Package

Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL® OR OEM
