NO.7100319 Паракс РК 75-2-310 BC 45% CCA PVC

Construction Parameters:

Inner Conductor

0.019"/0.48mm/25 AWG BC

Dielectric

0.144"/2.2mm  Solid PE

Shield

Copper clad aluminum
braid wire 40% coverage

Jacket

0.130"±0.006"/3.30±0.30mm PVC

Jacket Thickness

0.032"/0.81mm

Application

For Use in Longer CCTV Run Lengths

Electrical Characteristics:

Inner Conductor Resistance

The Max. at 20℃ shall be < 98 Ω/km

Capacitance

55±1 pF/m

Impedance

75±5 Ω

Return loss

20dB

Velocity of Propagation

0.81

Sparker Test (VAC)

Mechanical and Envrionmental Properties

Cable bend radius

10 times the cable diameter

Operating Temp Range

-20 ℃ to 60℃

Cable diamensions

0.130"±0.006"/3.30±0.30mm PVC

Cross Section

Attenuation(20℃):

Frequency (MHZ)

Max Attenuation(dB/100m)

10

4.90

50

10.60

200

21.60

470

34.00

862

46.70

1000

50.30

1350

59.10

1750

68.50

2150

78.10

2400

84.60

Order Informations:

Marking

HELLOSIGNAL PK75-2-310 BC 45% CCA PVC

CCTV COAXIAL CABLE 7100319 ×××M/FT

Package

Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL^® OR OEM
