NO.7100321 Паракс РК 75-2-311 BC 45% TCCA PE

Construction Parameters:

Inner Conductor

0.019"/0.48mm/25 AWG BC

Dielectric

0.144"/2.2mm  Solid PE

Shield 1

Al/PET

Shield 2

0.005"/0.12mm TCCA

Jacket

0.130"±0.006"/3.30±0.30mm PE

Jacket Thickness

0.032"/0.81mm

Application

For Use in Longer CCTV Run Lengths

Electrical Characteristics:

Inner Conductor Resistance

The Max. at 20℃ shall be < 98 Ω/km

Capacitance

55±1 pF/m

Impedance

75±5 Ω

Return loss

20dB

Velocity of Propagation

0.55

Sparker Test (VAC)

Mechanical and Envrionmental Properties

Cable bend radius

10 times the cable diameter

Operating Temp Range

-20 ℃ to 60℃ / -40 ℃ to 80℃

Cable diamensions

0.130"±0.006"/3.30±0.30mm PE

Cross Section

Attenuation(20℃):

Frequency (MHZ)

Max Attenuation(dB/100m)

10

5.16

50

10.20

200

19.20

470

30.00

862

41.30

1000

44.90

1350

52.80

1750

60.90

2150

68.90

2400

72.00

Order Informations:

Marking

HELLOSIGNAL PK75-2-311 BC 45% TCCA PE

CCTV COAXIAL CABLE 7100321 ×××M/FT

Package

Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL^® OR OEM
