NO.7100324 Паракс РК 75-2-311 BC 45% TC PVC

  • Паракс РК 75-2-311

  • hellosignal

  • 7100324

  • Coaxial Cable

  • 75 ohm

  • UL, ETL, CE, RoHS

  • 100m, 305m,500m,1000m,500ft,1000ft

  • roll, wooden spool, carton, pallet

  • 30KM

  • Normally 15 working days

  • NINGBO, SHANGHAI

  • T/T, L/C at sight, D/P at sight

Availability:

Specification

zion LOGOPK75-2-311 BC 45% TC PVC

75 Ohm CCTV coaxial Cable

NO.7100324

Construction Parameters:

Inner Conductor

0.019"/0.48mm/25 AWG BC

Dielectric

0.144"/2.2mm  Solid PE

Shield 1

Al/PET

Shield 2

0.005"/0.12mm TC

Jacket

0.130"±0.006"/3.30±0.30mm PVC

Jacket Thickness

0.032"/0.81mm

Application

For Use in Longer CCTV Run Lengths

Electrical Characteristics:

Inner Conductor Resistance


The Max. at 20 shall be < 98 Ω/km

Capacitance

55±1 pF/m


Impedance

75±5 Ω

Return loss

20dB

Velocity of Propagation

0.55

Sparker Test (VAC)



Mechanical and Envrionmental Properties

Cable bend radius

10 times the cable diameter

Operating Temp Range

-20  to 60

Cable diamensions

0.130"±0.006"/3.30±0.30mm PVC


Cross Section


Attenuation(20℃):

Frequency (MHZ)

Max Attenuation(dB/100m)


10

5.16


50

10.20


200

19.20


470

30.00


862

41.30


1000

44.90


1350

52.80


1750

60.90


2150

68.90


2400

72.00



Order Informations:

Marking

HELLOSIGNAL PK75-2-311 BC 45% TC PVC

CCTV COAXIAL CABLE 7100324 ×××M/FT

Package

Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL® OR OEM
