NO.7100357 Паракс РК 75-3-32 BC 88% CCA PVC

Construction Parameters:

Inner Conductor

0.024"/0.60mm/22 AWG BC

Dielectric

0.144"/2.70mm FPE

Shield

0.12mm Copper clad aluminum
braid wire 88% coverage

Jacket

0.170"±0.006"/4.50±0.30mmPVC

Jacket Thickness

0.032"/0.81mm

Application

For Use in Longer CCTV Run Lengths

Electrical Characteristics:

Inner Conductor Resistance

The Max. at 20℃ shall be < 63Ω/km

Capacitance

56.5±1 pF/m

Impedance

75±5 Ω

Return loss

between 5 and 1000MHz: > 20dB

Velocity of Propagation

0.82

Sparker Test (VAC)

Mechanical and Envrionmental Properties

Cable bend radius

10 times the cable diameter

Operating Temp Range

-20 ℃ to 60℃

Cable diamensions

0.130"±0.006"/3.30±0.30mm PVC

Cross Section

Attenuation(20℃):

Frequency (MHZ)

Max Attenuation(dB/100m)

10

3.54

50

8.04

200

16.50

470

25.80

862

35.80

1000

39.00

1350

46.10

1750

53.50

2150

60.00

2400

64.50

Order Informations:

Marking

HELLOSIGNAL PK75-3-32 BC 88% CCA PVC

CCTV COAXIAL CABLE 7100357 ×××M/FT

Package

Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …

Delivery time

Normally 25 days after received the deposit.

Brand

HELLOSIGNAL^® OR OEM
