Паракс РК 75-3-32
hellosignal
7100367
Coaxial Cable
75 ohm
UL, ETL, CE, RoHS
100m, 305m,500m,1000m,500ft,1000ft
roll, wooden spool, carton, pallet
30KM
Normally 15 working days
NINGBO, SHANGHAI
T/T, L/C at sight, D/P at sight
75 Ohm CCTV coaxial Cable NO.7100367 | |||
Construction Parameters: | |||
Inner Conductor | 0.024"/0.60mm/22 AWG CU | ||
Dielectric | 0.144"/2.70mm FPE | ||
Shield | 48/ 0.12mm CCAM | ||
Jacket | 4.4mmPVC | ||
Jacket Thickness | 0.032"/0.81mm | ||
Application | For Use in Longer CCTV Run Lengths | ||
Electrical Characteristics: | |||
Inner Conductor Resistance | The Max. at 20℃ shall be < 63Ω/km | ||
Capacitance | 56.5±1 pF/m | ||
Impedance | 75±5 Ω | ||
Return loss | between 5 and 1000MHz: > 20dB | ||
Velocity of Propagation | 0.82 | ||
Sparker Test (VAC) | |||
Mechanical and Envrionmental Properties | |||
Cable bend radius | 10 times the cable diameter | ||
Operating Temp Range | -20 ℃ to 60℃ | ||
Cable diamensions | 0.130"±0.006"/3.30±0.30mm PVC | ||
Cross Section | |||
| |||
Attenuation(20℃): | |||
Frequency (MHZ) | Max Attenuation(dB/100m) | ||
10 | 3.54 | ||
50 | 8.04 | ||
200 | 16.50 | ||
470 | 25.80 | ||
862 | 35.80 | ||
1000 | 39.00 | ||
1350 | 46.10 | ||
1750 | 53.50 | ||
2150 | 60.00 | ||
2400 | 64.50 | ||
Order Informations: | |||
Marking | HELLOSIGNAL РК75-3-32AИ CCTV COAXIAL CABLE 7100367 ×××M/FT | ||
Package | Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet … | ||
Delivery time | Normally 25 days after received the deposit. | ||
Brand | HELLOSIGNAL® OR OEM | ||
75 Ohm CCTV coaxial Cable NO.7100367 | |||
Construction Parameters: | |||
Inner Conductor | 0.024"/0.60mm/22 AWG CU | ||
Dielectric | 0.144"/2.70mm FPE | ||
Shield | 48/ 0.12mm CCAM | ||
Jacket | 4.4mmPVC | ||
Jacket Thickness | 0.032"/0.81mm | ||
Application | For Use in Longer CCTV Run Lengths | ||
Electrical Characteristics: | |||
Inner Conductor Resistance | The Max. at 20℃ shall be < 63Ω/km | ||
Capacitance | 56.5±1 pF/m | ||
Impedance | 75±5 Ω | ||
Return loss | between 5 and 1000MHz: > 20dB | ||
Velocity of Propagation | 0.82 | ||
Sparker Test (VAC) | |||
Mechanical and Envrionmental Properties | |||
Cable bend radius | 10 times the cable diameter | ||
Operating Temp Range | -20 ℃ to 60℃ | ||
Cable diamensions | 0.130"±0.006"/3.30±0.30mm PVC | ||
Cross Section | |||
| |||
Attenuation(20℃): | |||
Frequency (MHZ) | Max Attenuation(dB/100m) | ||
10 | 3.54 | ||
50 | 8.04 | ||
200 | 16.50 | ||
470 | 25.80 | ||
862 | 35.80 | ||
1000 | 39.00 | ||
1350 | 46.10 | ||
1750 | 53.50 | ||
2150 | 60.00 | ||
2400 | 64.50 | ||
Order Informations: | |||
Marking | HELLOSIGNAL РК75-3-32AИ CCTV COAXIAL CABLE 7100367 ×××M/FT | ||
Package | Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet … | ||
Delivery time | Normally 25 days after received the deposit. | ||
Brand | HELLOSIGNAL® OR OEM | ||
РК75-3-32AИ
