RG59
hellosignal
7102040
Coaxial Cable
75 ohm
UL, ETL, CE, RoHS
100m, 305m,500m,1000m,500ft,1000ft
roll, wooden spool, carton, pallet
30KM
Normally 15 working days
NINGBO, SHANGHAI
T/T, L/C at sight, D/P at sight
75 Ohm CCTV coaxial Cable NO.7102040 | ||
Construction Parameters: | ||
Inner Conductor | 7*0.18mm Bare Copper | |
Dielectric | 2.2mmSolid Polyethylene | |
Shield | 0.12mm CCA-Braid(95%) | |
Jacket | 4.05mm PVC/PE/LSZH | |
Power Wire Conductor | 2x(16*0.254mmCCA ) | |
Power wire Diameter of insulation | 0.075"/1.9mmHDPE (Red,Black) | |
Jacket | 5.05mm PVC/PE/LSZH | |
Application | For Use in Longer CCTV Run Lengths | |
Electrical Characteristics: | ||
Inner Conductor Resistance | 95 Ohms/KM at 20℃ | |
Capacitance | 52±2 pF/m | |
Impedance | 75 ± 3 Ω | |
Return loss | between 5 and 1000MHz: > 22dB | |
Velocity of Propagation | 0.66 | |
Sparker Test (VAC) | 3 | |
Mechanical and Envrionmental Properties | ||
Cable bend radius | 10 times the cable diameter | |
Operating Temp Range | -20 ℃ to 60℃ | |
Cable diamensions | 4.05×5.05mm | |
Cross Section | ||
| ||
Attenuation(20℃): | ||
Frequency (MHZ) | Max Attenuation(dB/100ft) | Max Attenuation (dB/100m) |
5 | 1.43 | 4.30 |
50 | 5.08 | 15.23 |
100 | 7.26 | 21.77 |
200 | 10.44 | 31.33 |
550 | 18.04 | 54.12 |
750 | 20.14 | 60.43 |
865 | 22.37 | 67.11 |
1000 | 25.90 | 77.69 |
Order Informations: | ||
Marking | HELLOSIGNAL RG59 Micro + 2C0.75 Figure 8 | |
Package | Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet … | |
Delivery time | Normally 25 days after received the deposit. | |
Brand | HELLOSIGNAL® OR OEM | |
75 Ohm CCTV coaxial Cable NO.7102040 | ||
Construction Parameters: | ||
Inner Conductor | 7*0.18mm Bare Copper | |
Dielectric | 2.2mmSolid Polyethylene | |
Shield | 0.12mm CCA-Braid(95%) | |
Jacket | 4.05mm PVC/PE/LSZH | |
Power Wire Conductor | 2x(16*0.254mmCCA ) | |
Power wire Diameter of insulation | 0.075"/1.9mmHDPE (Red,Black) | |
Jacket | 5.05mm PVC/PE/LSZH | |
Application | For Use in Longer CCTV Run Lengths | |
Electrical Characteristics: | ||
Inner Conductor Resistance | 95 Ohms/KM at 20℃ | |
Capacitance | 52±2 pF/m | |
Impedance | 75 ± 3 Ω | |
Return loss | between 5 and 1000MHz: > 22dB | |
Velocity of Propagation | 0.66 | |
Sparker Test (VAC) | 3 | |
Mechanical and Envrionmental Properties | ||
Cable bend radius | 10 times the cable diameter | |
Operating Temp Range | -20 ℃ to 60℃ | |
Cable diamensions | 4.05×5.05mm | |
Cross Section | ||
| ||
Attenuation(20℃): | ||
Frequency (MHZ) | Max Attenuation(dB/100ft) | Max Attenuation (dB/100m) |
5 | 1.43 | 4.30 |
50 | 5.08 | 15.23 |
100 | 7.26 | 21.77 |
200 | 10.44 | 31.33 |
550 | 18.04 | 54.12 |
750 | 20.14 | 60.43 |
865 | 22.37 | 67.11 |
1000 | 25.90 | 77.69 |
Order Informations: | ||
Marking | HELLOSIGNAL RG59 Micro + 2C0.75 Figure 8 | |
Package | Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet … | |
Delivery time | Normally 25 days after received the deposit. | |
Brand | HELLOSIGNAL® OR OEM | |
RG59 Micro + 2C0.75 Figure 8
