КВК-П-1,5
hellosignal
7102216
Coaxial Cable
75 ohm
UL, ETL, CE, RoHS
100m, 305m,500m,1000m,500ft,1000ft
roll, wooden spool, carton, pallet
30KM
Normally 15 working days
NINGBO, SHANGHAI
T/T, L/C at sight, D/P at sight
75 Ohm CCTV coaxial Cable NO.7102216 | ||
Construction Parameters: | ||
Inner Conductor | 0.25mmCu | |
Dielectric | 1.6mm Solid Polyethylene | |
Shield | 64×0.12mmCCA(90%) | |
Jacket | 3.1mm PVC | |
Power Wire Conductor | 2x(16x0.25mmCCA ) Stranded | |
Power wire Diameter of insulation | 2.0mm PVC (Red,Black) | |
Jacket | 5.0mm PVC Common | |
Application | For Use in Longer CCTV Run Lengths | |
Electrical Characteristics: | ||
Inner Conductor Resistance | The Max. at 20℃ shall be < 350 Ω/km | |
Capacitance | 68 ±3 pF/m | |
Impedance | 75 ± 5Ω | |
Return loss | 20dB | |
Velocity of Propagation | 0.82 | |
Sparker Test (VAC) | 3 | |
Mechanical and Envrionmental Properties | ||
Cable bend radius | 10 times the cable diameter | |
Operating Temp Range | -20 ℃ to 60℃ | |
Cable diamensions | 3.1×5.0mm | |
Cross Section | ||
| ||
Attenuation(20℃): | ||
Frequency (MHZ) | Max Attenuation(dB/100ft) | Max Attenuation (dB/100m) |
5 | 5.21 | |
50 | 16.45 | |
100 | 23.23 | |
300 | 40.22 | |
450 | 49.26 | |
865 | 68.28 | |
1000 | 73.42 | |
1750 | 97.12 | |
2150 | 107.70 | |
2500 | 116.07 | |
3000 | 127.15 | |
Order Informations: | ||
Marking | HELLOSIGNAL КВК-П-1,5+2х0.75,Figure 8 | |
Package | Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet … | |
Delivery time | Normally 25 days after received the deposit. | |
Brand | HELLOSIGNAL® OR OEM | |
75 Ohm CCTV coaxial Cable NO.7102216 | ||
Construction Parameters: | ||
Inner Conductor | 0.25mmCu | |
Dielectric | 1.6mm Solid Polyethylene | |
Shield | 64×0.12mmCCA(90%) | |
Jacket | 3.1mm PVC | |
Power Wire Conductor | 2x(16x0.25mmCCA ) Stranded | |
Power wire Diameter of insulation | 2.0mm PVC (Red,Black) | |
Jacket | 5.0mm PVC Common | |
Application | For Use in Longer CCTV Run Lengths | |
Electrical Characteristics: | ||
Inner Conductor Resistance | The Max. at 20℃ shall be < 350 Ω/km | |
Capacitance | 68 ±3 pF/m | |
Impedance | 75 ± 5Ω | |
Return loss | 20dB | |
Velocity of Propagation | 0.82 | |
Sparker Test (VAC) | 3 | |
Mechanical and Envrionmental Properties | ||
Cable bend radius | 10 times the cable diameter | |
Operating Temp Range | -20 ℃ to 60℃ | |
Cable diamensions | 3.1×5.0mm | |
Cross Section | ||
| ||
Attenuation(20℃): | ||
Frequency (MHZ) | Max Attenuation(dB/100ft) | Max Attenuation (dB/100m) |
5 | 5.21 | |
50 | 16.45 | |
100 | 23.23 | |
300 | 40.22 | |
450 | 49.26 | |
865 | 68.28 | |
1000 | 73.42 | |
1750 | 97.12 | |
2150 | 107.70 | |
2500 | 116.07 | |
3000 | 127.15 | |
Order Informations: | ||
Marking | HELLOSIGNAL КВК-П-1,5+2х0.75,Figure 8 | |
Package | Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet … | |
Delivery time | Normally 25 days after received the deposit. | |
Brand | HELLOSIGNAL® OR OEM | |
КВК-П-1,5+2х0.75,Figure 8
