NO.7110508 КПС нг(А)-FRLS 4×0.5mm² Unshielded Fire Alarm Cable

■ Specification:

ZION COMMUNICATION supplies a wide range of fire alarm cables designed for various applications in fire monitoring, fire detection, power-limited fire alarm systems, smoke detectors, signaling, audio circuits, control circuits, fire protective circuits, and security systems.

All fire alarm cables from HANGZHOU ZION COMMUNICATION CO., LTD comply with international standards within the industry. If you do not find the specific product you need, we offer the option of a special custom-designed cable. This allows you to choose between different constructions, jacket colors, or other materials.

Key Features

• Conductor Types: Solid conductor or multi-conductor cables.

• Shielding Options: Available in both shielded and unshielded versions.

• Variations:

• PVC: Polyvinyl chloride jacket.

• Plenum: Suitable for plenum spaces.

• Shielded: Protects against electromagnetic interference.

• Unshielded: Cost-effective for environments with minimal interference.

Applications

★Hotels★Theatres and Cinemas★Museums,Hospitals★Shopping Centres★Skyscrapers★Offices★Schools★Airports★Undergrounds and Tunnels★Railway Stations★Computer Centres★Alarm Systems★Traffic Control Systems★Fire Fighting Systems

Why Choose Us as Your Partner?

Price:

• You can get the ultimate reasonable factory price for fire alarm cables from us.

Service:

• Expert Export Team: Enjoy the best service from our expert team, including:

       Price for import and export

       Shipping time

       Document preparation

       Custom policy assistance

• Cost Savings: Our comprehensive service ultimately saves you costs and creates the most considerable value for your business.

Quality Guarantee:

• 100% Quality Testing: All products undergo 100% quality pass testing before being sent to customers.

• Lifetime Responsibility: We are responsible for all products during their normal lifetime, ensuring reliability and peace of mind.



18AWG 2/C SOL FPL-CL2

Fire Alarm Cables

NO.7110006

■ Cable Construction:

Conductor:

Material: Bare Copper Class 1

Configuration: 4 × 0.78 mm

Insulation:

Material: Silicone

Diameter over Dielectric: 0.070" nominal (1.8 mm)

Color Code:

Blu (Blue),Brn (Brown),Blk (Black),Gry (Gray)

Jacket:

Type: FRLS-PVC

Color: Red

Diameter over Jacket: 0.220" (5.6 mm)

Print Legend:

HELLOSIGNAL NO.7110508 КПС нг(А)-FRLS 4×0.5mm² Unshielded Cable MMDDYYYY

■ Electrical Properties:

Minimum Bend Radius: 8 × Diameter

Minimum DC Resistance: 37.4 Ω/km

Minimum Insulation Resistance: 100 MΩ/km

Installation Temperature: -10°C to +50°C

Test Voltage (rms value): 1000 V

Maximum Operating Voltage: 300 V

■ Test Standards:

Fire Endurance: 180 minutes under fire of 750 degrees without short-circuit.

Fire Hazard Class: P1.1.2.2.2 according to ГОСТ Р 31565-2012.

Cable Flame Retardant: Category A (ГОСТ Р IEC 60332-3-22-2005).

Toxicity Indicator: Not less than 41 g/m for the combustion products of polymeric material.

Smoke Generation: Does not reduce light transmittance by more than 50% during combustion and smoldering (ГОСТ Р IEC 61034-2-2005).

Design: Suitable for fixed installation for voltages up to 300 V AC at frequencies up to 10 kHz or 420 V DC.

■ Cross Section:



■ The Factory:

We have a study and design label, a professional team of engineers and skilled workers, advanced machines, and modern factories that can provide our customers with outstanding quality, service, and pricing.
Monthly Production Capacity:

Wire (Copper/copper clad aluminum) drawing: 500 Metric Tons+
Coaxial Cable: 14,000KM+
Telephone Cable: 10,000KM+
Data & Computer Cable: 12,200KM+
Security & Fire Alarm Cable: 10,000KM+
Other Cable Types: 10,000KM+
Cable Accessories: 180,000pcs+
Telecom Accessories: 180,000pcs+

■ Packing:

We have abundant types of packing for you, such as reels, plastic spools, wooden spool, pull boxes, colorful cartons, pallets, and many others. Also, our design team will supply you best solution of the packing for size, firm, and artistic appearance.

■ Order Information:

Package: Inquired Length on Reel, Pull Box, Plastic Spool,wooden Spool,pallet...

Delivery Time: Normally 25 days after receiving the deposit.

Brand: HELLOSIGNAL® or OEM
